2020 Caterpillar M315D
Product Description
Built for contractors who can't afford downtime, this 2020 Caterpillar M315D wheeled excavator is a dependable fleet addition ready to perform from day one. Sourced directly from Guangdong, China, this 15-ton machine delivers consistent hydraulic output at 35 MPa system pressure, powered by the proven CATERPILLAR C4.4 Acert engine producing 108 kW at 2,000 RPM across a 4.4L displacement.
Whether you need a reliable backup unit during peak seasons or a permanent second machine on a demanding site, the M315D brings full wheeled mobility at 34 km/h — keeping your crew productive across multiple locations without additional transport costs.
- Working Weight: 17,900 kg | 15-ton class
- Bucket Capacity: 0.78 / 0.34 / 1.1 m³ (backhoe)
- Maximum Digging Depth: 5,590 mm
- Maximum Excavation Radius: 8,910 mm
- Maximum Unloading Height: 6,950 mm
- Hydraulic System Capacity: 220 L
- Fuel Tank: 235 L for extended shift endurance
- Transport Dimensions: 8,480 mm (L) × 2,550 mm (W) × 3,150 mm (H)
Stocked in Guangdong and available for prompt global export — add a proven performer to your fleet without compromise.
| Specifications | Value |
|---|---|
| No. | 1080585 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 17900 |
| Bucket capacity (m³) | 0.78/0.34/1.1 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | CATERPILLAR C4.4 Acert |
| Rated power (kw/rpm) | 108(101)/2000 |
| Total displacement (L) | 4.4 |
| Forward speed (Km/h) | 34 |
| Rotation speed (rpm) | 10.5 |
| Main overflow set pressure (Mpa) | 35 |
| Fuel Tank (L) | 235 |
| Engine Oil changes (L) | 8 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 220 |
| Total transport length (mm) | 8480 |
| Total transport width (mm) | 2550 |
| Total transport height (mm) | 3150 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1262 |
| Wheelbase (mm) | 2550 |
| Total tire outside width (mm) | 2550 |
| Minimum ground clearance (mm) | 370 |
| Back end turning radius (mm) | 2215 |
| Maximum excavation radius (mm) | 8910 |
| Maximum digging depth (mm) | 5590 |
| Maximum excavation height (mm) | 10040 |
| Maximum unloading height (mm) | 6950 |
| Maximum vertical digging depth (mm) | 3720 |
Overview
No.1080585
Brand Name：
CaterpillarModel Number：
M315DYear：
2020
Location：
Guangdong China
Pub Date：
