2020 Caterpillar M315D







Product Description
Discover the robust and reliable Caterpillar M315D, a 2020 model available for purchase in Sichuan, China. This used heavy machine is designed to deliver exceptional performance and durability, making it an ideal choice for demanding industrial applications. Priced at 70,000 RMB, this excavator offers a cost-effective solution without compromising on quality or functionality.
- Year: 2020
- Brand: Caterpillar
- Model: M315D
- Location: Sichuan, China
- Price: 70,000 RMB
| Specifications | Value |
|---|---|
| No. | 1094620 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 17900 |
| Bucket capacity (m³) | 0.78/0.34/1.1 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | CATERPILLAR C4.4 Acert |
| Rated power (kw/rpm) | 108(101)/2000 |
| Total displacement (L) | 4.4 |
| Forward speed (Km/h) | 34 |
| Rotation speed (rpm) | 10.5 |
| Main overflow set pressure (Mpa) | 35 |
| Fuel Tank (L) | 235 |
| Engine Oil changes (L) | 8 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 220 |
| Total transport length (mm) | 8480 |
| Total transport width (mm) | 2550 |
| Total transport height (mm) | 3150 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1262 |
| Wheelbase (mm) | 2550 |
| Total tire outside width (mm) | 2550 |
| Minimum ground clearance (mm) | 370 |
| Back end turning radius (mm) | 2215 |
| Maximum excavation radius (mm) | 8910 |
| Maximum digging depth (mm) | 5590 |
| Maximum excavation height (mm) | 10040 |
| Maximum unloading height (mm) | 6950 |
| Maximum vertical digging depth (mm) | 3720 |
