2013 Caterpillar M318
Product Description
Built for wheeled mobility and precision digging, this 2013 Caterpillar M318 delivers 104.4 kW of reliable power through its CATERPILLAR 3116T engine. Operating at 19,500 kg working weight, the machine combines road-travel capability with excavation performance across urban reconstruction and infrastructure projects.
Operator-focused engineering defines this model. The elevated cab design at 3,100 mm provides commanding sightlines to bucket edge and surrounding traffic. Stability comes from a 2,750 mm wheelbase and 2,950 mm tire stance, while 375 mm ground clearance maintains maneuverability on uneven terrain. Hydraulic response is immediate, with main system pressure set at 33 MPa for controlled digging force.
- Maximum dig depth: 5,090 mm
- Maximum reach: 8,490 mm
- Top travel speed: 34 km/h
- Fuel capacity: 370 L for extended shifts
- Hydraulic reservoir: 300 L
Currently located in Jiangsu Suqian, this joint-venture manufactured unit suits contractors requiring mobility between sites without transport logistics. Cab comfort and hydraulic precision support full-day operation in demanding conditions.
| Specifications | Value |
|---|---|
| No. | 1029345 |
| Tonnage (tons) | 18 |
| Working weight (kg) | 19500 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | CATERPILLAR 3116T |
| Rated power (kw/rpm) | 104.4 |
| Total displacement (L) | 6.6 |
| Forward speed (Km/h) | 34 |
| Main overflow set pressure (Mpa) | 33 |
| Fuel Tank (L) | 370 |
| Hydraulic System (L) | 300 |
| Total transport width (mm) | 2950 |
| Full cab height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1280 |
| Wheelbase (mm) | 2750 |
| Total tire outside width (mm) | 2950 |
| Minimum ground clearance (mm) | 375 |
| Maximum excavation radius (mm) | 8490 |
| Maximum digging depth (mm) | 5090 |
| Maximum excavation height (mm) | 8530 |
| Maximum unloading height (mm) | 6080 |
| Maximum vertical digging depth (mm) | 2930 |
Overview
No.1029345
Brand Name：
CaterpillarModel Number：
M318Year：
2013
Location：
Jiangsu China
Pub Date：
