2016 Caterpillar M318
Product Description
Expand your operational capacity with this 2016 Caterpillar M318 wheeled excavator, currently positioned in Guilin, Guangxi. Built for contractors managing multiple jobsites simultaneously, this 18-ton machine delivers proven reliability as a fleet addition or dedicated backup unit. Powered by the robust CATERPILLAR 3116T engine producing 104.4 kW, it combines mobility with serious digging performance—8,490mm maximum reach and 5,090mm depth capability handle demanding excavation tasks without hesitation.
- Working Weight: 19,500 kg with excellent stability
- Mobility: 34 km/h road speed enables rapid site-to-site deployment
- Hydraulics: 33 MPa system pressure for consistent bucket performance
- Fuel Capacity: 370L tank supports extended operation between refills
- Compact Footprint: 2,950mm transport width navigates restricted access areas
- Vertical Reach: 8,530mm maximum excavation height for versatile applications
Joint venture manufacturing ensures OEM parts availability and service support. Ready to reduce downtime across your fleet operations when primary equipment
| Specifications | Value |
|---|---|
| No. | 1030456 |
| Tonnage (tons) | 18 |
| Working weight (kg) | 19500 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | CATERPILLAR 3116T |
| Rated power (kw/rpm) | 104.4 |
| Total displacement (L) | 6.6 |
| Forward speed (Km/h) | 34 |
| Main overflow set pressure (Mpa) | 33 |
| Fuel Tank (L) | 370 |
| Hydraulic System (L) | 300 |
| Total transport width (mm) | 2950 |
| Full cab height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1280 |
| Wheelbase (mm) | 2750 |
| Total tire outside width (mm) | 2950 |
| Minimum ground clearance (mm) | 375 |
| Maximum excavation radius (mm) | 8490 |
| Maximum digging depth (mm) | 5090 |
| Maximum excavation height (mm) | 8530 |
| Maximum unloading height (mm) | 6080 |
| Maximum vertical digging depth (mm) | 2930 |
see more
Overview
No.1030456
Brand Name：
CaterpillarModel Number：
M318Year：
2016
Location：
Guangxi China
Pub Date：
