2020 Caterpillar M318






Product Description
This 2020 Caterpillar M318 wheeled excavator is currently located in Sichuan, China and available for export. The machine represents Caterpillar's proven M-Series design, offering the mobility and versatility required for urban construction, utility work, and infrastructure projects.
Key features of the M318 platform include:
- Four-wheel drive and steering for superior maneuverability on road and site
- Hydraulic outriggers for enhanced stability during operation
- Caterpillar engine delivering reliable performance and fuel efficiency
- Spacious operator cabin with ergonomic controls
- Quick coupler compatibility for multiple attachment options
This unit has been maintained in excellent condition. Comprehensive inspection reports and shipping arrangements to your destination port can be coordinated upon request. Suitable for contractors requiring mobile excavation capabilities without transport limitations.
| Specifications | Value |
|---|---|
| No. | 1093786 |
| Tonnage (tons) | 18 |
| Working weight (kg) | 19500 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | CATERPILLAR 3116T |
| Rated power (kw/rpm) | 104.4 |
| Total displacement (L) | 6.6 |
| Forward speed (Km/h) | 34 |
| Main overflow set pressure (Mpa) | 33 |
| Fuel Tank (L) | 370 |
| Hydraulic System (L) | 300 |
| Total transport width (mm) | 2950 |
| Full cab height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1280 |
| Wheelbase (mm) | 2750 |
| Total tire outside width (mm) | 2950 |
| Minimum ground clearance (mm) | 375 |
| Maximum excavation radius (mm) | 8490 |
| Maximum digging depth (mm) | 5090 |
| Maximum excavation height (mm) | 8530 |
| Maximum unloading height (mm) | 6080 |
| Maximum vertical digging depth (mm) | 2930 |
