2016 Caterpillar M318D
Product Description
Built on decades of engineering excellence, this 2016 Caterpillar M318D wheeled excavator delivers proven performance for contractors demanding reliability in the used equipment market. Operating at 18 tons with a robust C6.6 Acert engine producing 129.8 kW, this machine combines mobility with serious digging capability—reaching 8,970 mm maximum excavation radius and 5,750 mm depth. Currently located in Liuzhou, Guangxi, it represents smart investment economics backed by Caterpillar's unmatched global parts network and superior resale retention.
- Brand Security: Caterpillar parts available worldwide; technician support in 190+ countries
- Performance Specs: 20,100 kg working weight, 0.74 m³ bucket capacity, 37 km/h travel speed
- Hydraulic Power: 35 MPa system pressure, 268.8 L hydraulic capacity for responsive control
- Operational Range: 386.1 L fuel tank, 9,710 mm maximum excavation height
- Resale Advantage: Cat yellow iron consistently outperforms competitors in value retention
Investing in used Caterpillar equipment means buying into a support ecosystem that protects your asset long-term.
| Specifications | Value |
|---|---|
| No. | 1030537 |
| Tonnage (tons) | 18 |
| Working weight (kg) | 20100 |
| Bucket capacity (m³) | 0.74/0.57/1.6 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | CATERPILLAR C6.6 Acert |
| Rated power (kw/rpm) | 129.8/123.8 |
| Total displacement (L) | 6.6 |
| Forward speed (Km/h) | 37 |
| Rotation speed (rpm) | 10.5 |
| Main overflow set pressure (Mpa) | 35 |
| Fuel Tank (L) | 386.1 |
| Engine Oil changes (L) | 15.1 |
| Coolant (L) | 32.2 |
| Hydraulic System (L) | 268.8 |
| Total transport length (mm) | 8870 |
| Total transport width (mm) | 2550 |
| Total transport height (mm) | 3170 |
| Full cab height (mm) | 3170 |
| Counterweight ground clearance (mm) | 1280 |
| Wheelbase (mm) | 2600 |
| Total tire outside width (mm) | 2550 |
| Minimum ground clearance (mm) | 370 |
| Back end turning radius (mm) | 2500 |
| Maximum excavation radius (mm) | 8970 |
| Maximum digging depth (mm) | 5750 |
| Maximum excavation height (mm) | 9710 |
| Maximum unloading height (mm) | 6700 |
| Maximum vertical digging depth (mm) | 3220 |
see more
Overview
No.1030537
Brand Name：
CaterpillarModel Number：
M318DYear：
2016
Location：
Guangxi China
Pub Date：
