2020 Caterpillar M318D
Product Description
With a robust 18-ton working weight and powered by the CATERPILLAR C6.6 Acert engine, this 2020 Caterpillar M318D excavator is designed for immediate site deployment. Located in Hunan, China, it excels in digging, grading, and demolition tasks. Equipped with a versatile backhoe bucket, it offers a maximum digging depth of 5750 mm and a maximum excavation height of 9710 mm, ensuring efficiency on any job site.
- Engine: CATERPILLAR C6.6 Acert, 129.8 kW at 123.8 rpm
- Bucket capacity: 0.74/0.57/1.6 m³
- Fuel Tank: 386.1 L
- Total transport dimensions: 8870 mm (length) x 2550 mm (width) x 3170 mm (height)
- Maximum unloading height: 6700 mm
Ready to tackle tough jobs, this excavator features a 35 Mpa main overflow set pressure and a 268.8 L hydraulic system, providing the power and precision needed for demanding applications. Its 37 km/h forward speed ensures quick movement around the site, making it an indispensable asset for your construction projects.
| Specifications | Value |
|---|---|
| No. | 1057236 |
| Tonnage (tons) | 18 |
| Working weight (kg) | 20100 |
| Bucket capacity (m³) | 0.74/0.57/1.6 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | CATERPILLAR C6.6 Acert |
| Rated power (kw/rpm) | 129.8/123.8 |
| Total displacement (L) | 6.6 |
| Forward speed (Km/h) | 37 |
| Rotation speed (rpm) | 10.5 |
| Main overflow set pressure (Mpa) | 35 |
| Fuel Tank (L) | 386.1 |
| Engine Oil changes (L) | 15.1 |
| Coolant (L) | 32.2 |
| Hydraulic System (L) | 268.8 |
| Total transport length (mm) | 8870 |
| Total transport width (mm) | 2550 |
| Total transport height (mm) | 3170 |
| Full cab height (mm) | 3170 |
| Counterweight ground clearance (mm) | 1280 |
| Wheelbase (mm) | 2600 |
| Total tire outside width (mm) | 2550 |
| Minimum ground clearance (mm) | 370 |
| Back end turning radius (mm) | 2500 |
| Maximum excavation radius (mm) | 8970 |
| Maximum digging depth (mm) | 5750 |
| Maximum excavation height (mm) | 9710 |
| Maximum unloading height (mm) | 6700 |
| Maximum vertical digging depth (mm) | 3220 |
Overview
No.1057236
Brand Name：
CaterpillarModel Number：
M318DYear：
2020
Location：
Hunan China
Pub Date：
