FairTradeMachinery presents a 2017 Doosan DX300LC-7 crawler excavator, currently located in Gansu Province, China. This 30-ton class hydraulic excavator from Doosan's proven LC-7 series offers reliable performance for demanding earthmoving and construction applications.
The DX300LC-7 features Doosan's fuel-efficient engine technology and robust undercarriage designed for extended service life. This unit has been maintained in idle storage and is now available for immediate sale to qualified buyers seeking dependable mid-size excavation equipment.
- Year of Manufacture: 2017
- Model: DX300LC-7
- Location: Gansu, China
- Category: Crawler Excavator
- Status: Pre-owned, stored idle
Ideal for contractors and fleet operators requiring a versatile excavator with proven durability. Contact FairTradeMachinery for detailed specifications, current condition assessment, and export logistics support.
| Specifications | Value |
|---|---|
| No. | 1083700 |
| Tonnage (tons) | 30 |
| Working weight (kg) | 29600 |
| Bucket capacity (m³) | 1.27 |
| Boom length (mm) | 6245/10000 |
| Rod length (mm) | 2500/3750/3100/7000 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | DE08TIS |
| Rated power (kw/rpm) | 147(200) / 1900 |
| Cylinder diameter × stroke (mm) | 111 x 139 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 8.07 |
| Working form | 4-stroke, water-cooled, direct spray |
| Ground specific pressure (Kpa) | 56 |
| Rotation speed (rpm) | 10.1 |
| Bucket digging force (kN) | 188 / 199.9 |
| Rod digging force (kN) | 127.5 / 135.3 |
| Travel speed (km/h) | 5.0 / 3.1 |
| Turning torque (Nm) | 92 |
| Main overflow set pressure (Mpa) | Standard 27.9/ Supercharged 34.3 |
| Maximum flow of main pump (l/min) | 2 x 246 |
| Traveling Hydraulic Circuit (Mpa) | 32.5 |
| Rotary Hydraulic Circuit (Mpa) | 27.9 |
| Main pump type | Variable axial plunger pump |
| Pilot pump flow (L/min) | 28.5 |
| Fuel Tank (L) | 450 |
| Hydraulic Tank (L) | 290 |
| Total transport length (mm) | 10620 |
| Total transport width (mm) | 3200 |
| Total transport height (mm) | 3365(to top of the upper arm) |
| Full cab height (mm) | 3255 |
| Counterweight ground clearance (mm) | 1175 |
| Minimum ground clearance (mm) | 500 |
| Back end turning radius (mm) | 3200 |
| Onboard width (mm) | 2960 |
| Total track length (mm) | 4930 |
| Track gauge (mm) | 2600 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3200 |
| Track ground length (mm) | 4010 |
| Maximum digging radius (mm) | 10705 |
| Maximum digging depth (mm) | 7190 |
| Maximum excavation height (mm) | 10495 |
| Maximum unloading height (mm) | 7470 |
| Maximum vertical digging depth (mm) | 6220 |
| Maximum excavation radius of stop surface (mm) | 9950/11105/10540/17320 |
| Maximum effective digging depth (mm) | 6505/7810/7150/13680 |
