Product Description
Discover the reliability and power of this 2015 Doosan 60-7, currently located in Zhejiang, China. This machine is in excellent condition, actively working on construction sites, and is known for its robust performance. Equipped with a powerful engine that has shown no signs of trouble, it ensures consistent and efficient operation. The hydraulic system is strong and reliable, providing the force needed for demanding tasks. Additionally, the original air conditioning system remains fully functional, ensuring operator comfort even in challenging conditions. Ideal for businesses looking for a dependable and high-performing piece of equipment.
- Year: 2015
- Brand: Doosan
- Model: 60-7
- Location: Zhejiang, China
- Active on construction sites
- Powerful and reliable engine
- Strong hydraulic system
- Functional original air conditioning
| Specifications | Value |
|---|---|
| No. | 1129838 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5550 |
| Bucket capacity (m³) | 0.09-0.2 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Yantai, Shandong Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 38.1/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Working form | Air-to-air cooling |
| Bucket digging force (kN) | 37.7 |
| Rod digging force (kN) | 28.4 |
| Maximum flow of main pump (l/min) | 55 x 2 |
| Traveling Hydraulic Circuit (Mpa) | 20.6 |
| Rotary Hydraulic Circuit (Mpa) | 21.6 |
| Main pump type | Variable axial piston pump ×2 |
| Working Hydraulic Circuit (Mpa) | 20.6 |
| Pilot pump flow (L/min) | 9.9 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880 |
| Total transport height (mm) | 2575 |
| Full cab height (mm) | 2575 |
| Minimum ground clearance (mm) | 350 |
| Back end turning radius (mm) | 1650 |
| Onboard width (mm) | 1885 |
| Total track length (mm) | 2540 |
| Track gauge (mm) | 1480 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 1880 |
| Track ground length (mm) | 1990 |
| Maximum digging radius (mm) | 6150 |
| Maximum digging depth (mm) | 3820 |
| Maximum excavation height (mm) | 5760 |
| Maximum unloading height (mm) | 4030 |
