Product Description
Proven in demanding conditions since 2016, this Doosan DH215-7 excavator demonstrates the durability that has made it a trusted workhorse across construction sites worldwide. Operating at 21 tons with a robust 147kW Doosan DB58T1 engine, this machine delivers consistent performance backed by joint venture manufacturing quality from Yantai, Shandong Province.
Built to last through challenging projects, it offers impressive reach with a 9970mm maximum digging radius and 6660mm maximum digging depth. The 0.86m³ bucket capacity, combined with 136.2kN bucket digging force, ensures productive material handling in every cycle. Multiple rod length configurations (2400/2900/3500mm) provide versatility for varied applications.
- Working Weight: 20,600 kg for excellent stability
- Fuel Capacity: 350L for extended operation
- Travel Speed: 3.1-5.4 km/h for efficient mobility
- Track Width: 600mm for superior ground contact
- Current Location: Wenzhou, Zhejiang Province
With years of field-proven reliability already logged, this DH215-7 represents dependable heavy equipment engineered for longevity and consistent returns on investment.
| Specifications | Value |
|---|---|
| No. | 1031367 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 20600 |
| Bucket capacity (m³) | 0.86 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 2400/2900/3500 |
| Country of origin | Yantai, Shandong Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Doosan DB58T1 |
| Rated power (kw/rpm) | 147/2000 |
| Cooling mode | Air cooling |
| Ground specific pressure (Kpa) | 52 |
| Rotation speed (rpm) | 12.1 |
| Bucket digging force (kN) | 136.2/144.1 |
| Rod digging force (kN) | 100/104.9 |
| Travel speed (km/h) | 3.1-5.4 |
| Fuel Tank (L) | 350 |
| Total transport length (mm) | 9550 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3100 |
| Full cab height (mm) | 3100 |
| Minimum ground clearance (mm) | 480 |
| Back end turning radius (mm) | 2750 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 22800 |
| Maximum digging radius (mm) | 9970 |
| Maximum digging depth (mm) | 6660 |
| Maximum excavation height (mm) | 9660 |
| Maximum unloading height (mm) | 6810 |
| Maximum vertical digging depth (mm) | 5600 |
| Maximum excavation radius of stop surface (mm) | 9780 |
| Maximum effective digging depth (mm) | 6460 |
