Product Description
Ready to deploy from 广西桂林 (Guilin, Guangxi), this 2018 Doosan DH215-7 eliminates factory wait times and gets your project moving immediately. With a 21-ton operating weight and robust 147kW Doosan DB58T1 engine, this mid-size excavator delivers proven performance across construction, mining, and infrastructure applications. Available now for fast shipment to your site—no production delays, no customs headaches on domestic transfers.
- Immediate Availability: Skip 6-12 month lead times; secure this machine and start work within days
- Powerful Digging Performance: 0.86m³ bucket capacity, 9970mm max reach, 6660mm digging depth, and 144.1kN bucket force tackle demanding excavation tasks
- Versatile Boom Configurations: Multiple rod options (2400/2900/3500mm) adapt to trenching, loading, and precision work
- Proven Reliability: Doosan DB58T1 air-cooled engine rated at 147kW/2000rpm ensures consistent productivity in harsh conditions
- Logistics-Ready Dimensions: 9550mm transport length fits standard lowboy trailers; positioned in Guilin for rapid deployment across southern China or export terminals
| Specifications | Value |
|---|---|
| No. | 1031048 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 20600 |
| Bucket capacity (m³) | 0.86 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 2400/2900/3500 |
| Country of origin | Yantai, Shandong Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Doosan DB58T1 |
| Rated power (kw/rpm) | 147/2000 |
| Cooling mode | Air cooling |
| Ground specific pressure (Kpa) | 52 |
| Rotation speed (rpm) | 12.1 |
| Bucket digging force (kN) | 136.2/144.1 |
| Rod digging force (kN) | 100/104.9 |
| Travel speed (km/h) | 3.1-5.4 |
| Fuel Tank (L) | 350 |
| Total transport length (mm) | 9550 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3100 |
| Full cab height (mm) | 3100 |
| Minimum ground clearance (mm) | 480 |
| Back end turning radius (mm) | 2750 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 22800 |
| Maximum digging radius (mm) | 9970 |
| Maximum digging depth (mm) | 6660 |
| Maximum excavation height (mm) | 9660 |
| Maximum unloading height (mm) | 6810 |
| Maximum vertical digging depth (mm) | 5600 |
| Maximum excavation radius of stop surface (mm) | 9780 |
| Maximum effective digging depth (mm) | 6460 |
