Product Description
2018 Doosan DH215-7 hydraulic excavator available from Shandong, China. This 21-ton class machine features Doosan's proven DH215-7 platform with reliable hydraulic systems and solid structural integrity. Well-maintained unit showing consistent performance in field operations.
The DH215-7 delivers dependable power and control for earthmoving, grading, and material handling applications. Standard boom and arm configuration with bucket attachment included. Machine has been operated under normal working conditions with routine maintenance records available.
- Year: 2018
- Model: Doosan DH215-7
- Operating Weight: ~21,500 kg
- Location: Shandong Province, China
- Condition: Used, operational
Suitable for contractors and operators seeking a mid-size excavator with established performance history. Inspection welcomed. Contact for detailed specifications and current availability.
| Specifications | Value |
|---|---|
| No. | 1139455 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 20600 |
| Bucket capacity (m³) | 0.86 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 2400/2900/3500 |
| Country of origin | Yantai, Shandong Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Doosan DB58T1 |
| Rated power (kw/rpm) | 147/2000 |
| Cooling mode | Air cooling |
| Ground specific pressure (Kpa) | 52 |
| Rotation speed (rpm) | 12.1 |
| Bucket digging force (kN) | 136.2/144.1 |
| Rod digging force (kN) | 100/104.9 |
| Travel speed (km/h) | 3.1-5.4 |
| Fuel Tank (L) | 350 |
| Total transport length (mm) | 9550 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3100 |
| Full cab height (mm) | 3100 |
| Minimum ground clearance (mm) | 480 |
| Back end turning radius (mm) | 2750 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 22800 |
| Maximum digging radius (mm) | 9970 |
| Maximum digging depth (mm) | 6660 |
| Maximum excavation height (mm) | 9660 |
| Maximum unloading height (mm) | 6810 |
| Maximum vertical digging depth (mm) | 5600 |
| Maximum excavation radius of stop surface (mm) | 9780 |
| Maximum effective digging depth (mm) | 6460 |
