Product Description
Built for demanding jobsites, this 2019 Doosan DH215-7 delivers 21 tons of proven excavation performance with operator-first engineering. Powered by a Doosan DB58T1 engine generating 147 kW at 2000 rpm, this machine combines responsive hydraulics with exceptional stability across uneven terrain. The spacious cab offers commanding 360-degree visibility, reducing blind spots and enhancing safety during complex maneuvers.
Operators benefit from intuitive controls and a well-designed workspace that minimizes fatigue during extended shifts. With a ground-specific pressure of just 52 kPa and a 2750 mm rear-end turning radius, this excavator maintains excellent balance while maximizing maneuverability in confined spaces. The 0.86 m³ bucket capacity and 136.2 kN bucket digging force tackle tough materials efficiently, while multiple arm configurations (2400/2900/3500 mm) adapt to varied applications.
- Maximum digging reach: 9970 mm
- Maximum digging depth: 6660 mm
- Operating weight: 20,600 kg
- Fuel capacity: 350 L for extended runtime
- Currently located in Hangzhou, Zhejiang
| Specifications | Value |
|---|---|
| No. | 1026081 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 20600 |
| Bucket capacity (m³) | 0.86 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 2400/2900/3500 |
| Country of origin | Yantai, Shandong Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Doosan DB58T1 |
| Rated power (kw/rpm) | 147/2000 |
| Cooling mode | Air cooling |
| Ground specific pressure (Kpa) | 52 |
| Rotation speed (rpm) | 12.1 |
| Bucket digging force (kN) | 136.2/144.1 |
| Rod digging force (kN) | 100/104.9 |
| Travel speed (km/h) | 3.1-5.4 |
| Fuel Tank (L) | 350 |
| Total transport length (mm) | 9550 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3100 |
| Full cab height (mm) | 3100 |
| Minimum ground clearance (mm) | 480 |
| Back end turning radius (mm) | 2750 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 22800 |
| Maximum digging radius (mm) | 9970 |
| Maximum digging depth (mm) | 6660 |
| Maximum excavation height (mm) | 9660 |
| Maximum unloading height (mm) | 6810 |
| Maximum vertical digging depth (mm) | 5600 |
| Maximum excavation radius of stop surface (mm) | 9780 |
| Maximum effective digging depth (mm) | 6460 |
