Product Description
Engineered for precision and all-day productivity, this 2020 Doosan DH215-7 excavator delivers commanding performance in the 21-ton class. Powered by a robust Doosan DB58T1 engine generating 147 kW at 2000 rpm, operators benefit from responsive hydraulics and exceptional fuel efficiency from the 350-liter tank. The spacious cab offers panoramic visibility across the 9,970 mm maximum digging radius, while intuitive controls reduce fatigue during extended shifts.
- Operating Weight: 20,600 kg with 0.86 m³ bucket capacity
- Digging Performance: 6,660 mm maximum depth, 9,660 mm maximum height
- Stability & Control: 2,750 mm rear turning radius, 52 kPa ground pressure for secure footing
- Operator Comfort: Full-height cab (3,100 mm) with superior sightlines and ergonomic layout
- Versatile Reach: Multiple arm configurations (2,400/2,900/3,500 mm) for varied applications
- Current Location: Luzhou, Sichuan Province
Built for contractors demanding reliability and operator satisfaction, this DH215-7 combines proven Doosan engineering with practical worksite versatility.
| Specifications | Value |
|---|---|
| No. | 1023564 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 20600 |
| Bucket capacity (m³) | 0.86 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 2400/2900/3500 |
| Country of origin | Yantai, Shandong Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Doosan DB58T1 |
| Rated power (kw/rpm) | 147/2000 |
| Cooling mode | Air cooling |
| Ground specific pressure (Kpa) | 52 |
| Rotation speed (rpm) | 12.1 |
| Bucket digging force (kN) | 136.2/144.1 |
| Rod digging force (kN) | 100/104.9 |
| Travel speed (km/h) | 3.1-5.4 |
| Fuel Tank (L) | 350 |
| Total transport length (mm) | 9550 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3100 |
| Full cab height (mm) | 3100 |
| Minimum ground clearance (mm) | 480 |
| Back end turning radius (mm) | 2750 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 22800 |
| Maximum digging radius (mm) | 9970 |
| Maximum digging depth (mm) | 6660 |
| Maximum excavation height (mm) | 9660 |
| Maximum unloading height (mm) | 6810 |
| Maximum vertical digging depth (mm) | 5600 |
| Maximum excavation radius of stop surface (mm) | 9780 |
| Maximum effective digging depth (mm) | 6460 |
