Product Description
Built for immediate deployment on demanding jobsites, this 2016 Doosan DH215-9 delivers 21-ton capacity with proven Yantai manufacturing quality. Powered by a robust Doosan DE08TIS water-cooled engine generating 110kW at 1950rpm, this excavator handles deep foundation work, trenching, and heavy earthmoving with consistent hydraulic performance. The 5700mm boom and 2900mm arm provide a maximum digging reach of 9970mm and depth of 6660mm—ideal for utility installation, site preparation, and bulk excavation projects.
- Operating weight: 21,000kg with 0.86-1.0m³ bucket capacity
- Dual variable piston pumps: 2×211 L/min flow for responsive digging cycles
- Maximum digging height: 9660mm for loading high-sided trucks
- Travel speed: 5.4km/h for efficient site repositioning
- Hydraulic system: 34.3MPa supercharged working circuit for breakout force
- Fuel capacity: 350L tank supports extended shift operation
- Transport dimensions: 9600×2800×2870mm for standard flatbed hauling
Currently located in Lishui, Zhejiang Province. Machine specifications verified and ready for immediate shipping worldwide.
| Specifications | Value |
|---|---|
| No. | 1027870 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21000 |
| Bucket capacity (m³) | 0.86/1.0 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 2900 |
| Country of origin | Yantai, Shandong Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Doosan Doosan DE08TIS |
| Rated power (kw/rpm) | 110/1950 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 8.071 |
| Working form | Direct injection mechanically controlled engine |
| Ground specific pressure (Kpa) | 49 |
| Rotation speed (rpm) | 12.4 |
| Travel speed (km/h) | 5.4/3.1 |
| Rotary hydraulic motor type | Axial plunger type ×1 |
| Type of walking hydraulic motor | Axial plunger type x 2 |
| Maximum flow of main pump (l/min) | 2 x 211 |
| Traveling Hydraulic Circuit (Mpa) | 32.4 |
| Rotary Hydraulic Circuit (Mpa) | 27.5 |
| Main pump type | Variable piston pump |
| Working Hydraulic Circuit (Mpa) | Standard 32.4/ Supercharged 34.3 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120 x 80 x 1050 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-135 x 95 x 1538 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-120 x 85 x 1245 |
| Fuel Tank (L) | 350 |
| Hydraulic Tank (L) | 240 |
| Engine Oil changes (L) | 28 |
| Coolant (L) | 42 |
| Total transport length (mm) | 9600 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2870(to top of boom) |
| Full cab height (mm) | 3000 |
| Counterweight ground clearance (mm) | 1105 |
| Minimum ground clearance (mm) | 480 |
| Minimum turning radius of front working device (mm) | 3960 |
| Back end turning radius (mm) | 2840 |
| Total track length (mm) | 4065 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Maximum digging radius (mm) | 9970 |
| Maximum digging depth (mm) | 6660 |
| Maximum excavation height (mm) | 9660 |
| Maximum unloading height (mm) | 6810 |
| Maximum vertical digging depth (mm) | 5600 |
| Maximum excavation radius of stop surface (mm) | 9780 |
