Product Description
Built for all-day productivity, this 2017 Doosan DH215-9 delivers reliable performance in a 21-ton platform engineered for operator confidence. Powered by a Doosan DE08TIS engine producing 110 kW at 1950 rpm, this crawler excavator combines proven hydraulic efficiency with exceptional machine control across demanding jobsites.
Operators benefit from superior visibility and ergonomic design that reduce fatigue during extended shifts. The spacious cab sits 3000mm high, offering commanding sightlines to the 5700mm boom and 2900mm arm. Responsive dual variable piston pumps deliver 2×211 L/min flow, ensuring smooth simultaneous functions and precise bucket placement. With a minimum turning radius of just 3960mm and 2840mm rear swing radius, maneuverability in confined areas becomes routine.
Key Specifications:
- Maximum digging reach: 9970mm
- Maximum digging depth: 6660mm
- Bucket capacity: 0.86–1.0 m³
- Operating weight: 21,000 kg
- Track width: 600mm
- Currently located in Hunan, China
Stability remains uncompromised thanks to optimized 49 kPa ground pressure and robust undercarriage design. Contact Fair Trade Machinery today for complete ins
| Specifications | Value |
|---|---|
| No. | 1033043 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21000 |
| Bucket capacity (m³) | 0.86/1.0 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 2900 |
| Country of origin | Yantai, Shandong Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Doosan Doosan DE08TIS |
| Rated power (kw/rpm) | 110/1950 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 8.071 |
| Working form | Direct injection mechanically controlled engine |
| Ground specific pressure (Kpa) | 49 |
| Rotation speed (rpm) | 12.4 |
| Travel speed (km/h) | 5.4/3.1 |
| Rotary hydraulic motor type | Axial plunger type ×1 |
| Type of walking hydraulic motor | Axial plunger type x 2 |
| Maximum flow of main pump (l/min) | 2 x 211 |
| Traveling Hydraulic Circuit (Mpa) | 32.4 |
| Rotary Hydraulic Circuit (Mpa) | 27.5 |
| Main pump type | Variable piston pump |
| Working Hydraulic Circuit (Mpa) | Standard 32.4/ Supercharged 34.3 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120 x 80 x 1050 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-135 x 95 x 1538 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-120 x 85 x 1245 |
| Fuel Tank (L) | 350 |
| Hydraulic Tank (L) | 240 |
| Engine Oil changes (L) | 28 |
| Coolant (L) | 42 |
| Total transport length (mm) | 9600 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2870(to top of boom) |
| Full cab height (mm) | 3000 |
| Counterweight ground clearance (mm) | 1105 |
| Minimum ground clearance (mm) | 480 |
| Minimum turning radius of front working device (mm) | 3960 |
| Back end turning radius (mm) | 2840 |
| Total track length (mm) | 4065 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Maximum digging radius (mm) | 9970 |
| Maximum digging depth (mm) | 6660 |
| Maximum excavation height (mm) | 9660 |
| Maximum unloading height (mm) | 6810 |
| Maximum vertical digging depth (mm) | 5600 |
| Maximum excavation radius of stop surface (mm) | 9780 |
