Product Description
With a robust 22-ton working weight and a powerful Doosan DB58TIS engine, this 2014 Doosan DH220-9E excavator is designed for immediate deployment on your worksite. Located in 四川泸州, it features a 0.93 m³ bucket capacity, making it ideal for heavy-duty digging and grading tasks. The machine's 110 kW of power at 1950 rpm ensures efficient performance, while the 5700 mm boom and 2900 mm rod provide extensive reach and versatility.
- Bucket digging force: 136.2/144.1 kN
- Travel speed: 3.1-5.4 km/h
- Maximum digging depth: 6655 mm
- Fuel tank capacity: 310 L
- Total transport dimensions: 9645 x 2990 x 3025 mm (LxWxH)
Ready to handle tough jobs, this excavator offers reliable performance and durability. Its advanced hydraulic systems and solid construction make it a dependable choice for demolition and other demanding applications. Get ready to tackle your next project with confidence and efficiency.
| Specifications | Value |
|---|---|
| No. | 1033894 |
| Tonnage (tons) | 22 |
| Working weight (kg) | 22000 |
| Bucket capacity (m³) | 0.93 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Doosan DB58TIS |
| Rated power (kw/rpm) | 110/1950 |
| Cylinder diameter × stroke (mm) | 111 x 139 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 8.07 |
| Ground specific pressure (Kpa) | 46 |
| Rotation speed (rpm) | 12.1 |
| Bucket digging force (kN) | 136.2/144.1 |
| Rod digging force (kN) | 100/104.9 |
| Travel speed (km/h) | 3.1-5.4 |
| Traveling Hydraulic Circuit (Mpa) | 32.4 |
| Rotary Hydraulic Circuit (Mpa) | 27.5 |
| Working Hydraulic Circuit (Mpa) | 32.4 |
| Pilot pump flow (L/min) | 2 x 212 |
| Fuel Tank (L) | 310 |
| Engine Oil changes (L) | 32 |
| Coolant (L) | 42 |
| Hydraulic System (L) | 135 |
| Total transport length (mm) | 9645 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3025 |
| Full cab height (mm) | 3025 |
| Counterweight ground clearance (mm) | 1105 |
| Minimum ground clearance (mm) | 480 |
| Minimum turning radius of front working device (mm) | 3685 |
| Back end turning radius (mm) | 2840 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 4440 |
| Maximum digging radius (mm) | 9965 |
| Maximum digging depth (mm) | 6655 |
| Maximum excavation height (mm) | 9660 |
| Maximum unloading height (mm) | 6800 |
| Maximum vertical digging depth (mm) | 5980 |
| Maximum excavation radius of stop surface (mm) | 9780 |
| Maximum effective digging depth (mm) | 5885 |
