Product Description
Ready to deploy from 湖南 (Hunan), this 2016 Doosan DH60-7 compact excavator eliminates factory wait times and gets your crew working faster. Powered by a reliable Yanmar 4TNV94L engine delivering 38.1 kW at 2200 rpm, this 6-ton machine combines proven hydraulic performance with immediate availability. Dual variable axial piston pumps supply 55 L/min each, while the water-cooled 4-cylinder configuration ensures consistent operation across demanding job sites.
- Immediate Availability: Skip months of factory lead times—available now in 湖南
- Compact Footprint: 1880 mm transport width, 1650 mm rear swing radius for confined urban sites
- Proven Reach: 6150 mm maximum digging radius, 3820 mm dig depth
- Reliable Power: Yanmar 4TNV94L engine, water-cooled, 38.1 kW rated output
- Hydraulic Strength: 37.7 kN bucket force, 28.4 kN arm force
- Fast Deployment: Source locally from 湖南, minimize logistics delays
Secure this joint-venture quality excavator and mobilize your operations without the typical procurement delays. Contact Fair Trade Machinery today for immediate dispatch arran
| Specifications | Value |
|---|---|
| No. | 1026635 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5550 |
| Bucket capacity (m³) | 0.09-0.2 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Yantai, Shandong Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 38.1/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Working form | Air-to-air cooling |
| Bucket digging force (kN) | 37.7 |
| Rod digging force (kN) | 28.4 |
| Maximum flow of main pump (l/min) | 55 x 2 |
| Traveling Hydraulic Circuit (Mpa) | 20.6 |
| Rotary Hydraulic Circuit (Mpa) | 21.6 |
| Main pump type | Variable axial piston pump ×2 |
| Working Hydraulic Circuit (Mpa) | 20.6 |
| Pilot pump flow (L/min) | 9.9 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880 |
| Total transport height (mm) | 2575 |
| Full cab height (mm) | 2575 |
| Minimum ground clearance (mm) | 350 |
| Back end turning radius (mm) | 1650 |
| Onboard width (mm) | 1885 |
| Total track length (mm) | 2540 |
| Track gauge (mm) | 1480 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 1880 |
| Track ground length (mm) | 1990 |
| Maximum digging radius (mm) | 6150 |
| Maximum digging depth (mm) | 3820 |
| Maximum excavation height (mm) | 5760 |
| Maximum unloading height (mm) | 4030 |
