Product Description
Maximize ROI with this 2016 Doosan DH60-7 mini excavator—proven performance at a fraction of new equipment costs. Built by Doosan's joint venture facility in Yantai, Shandong, this 6-ton workhorse delivers professional-grade capability without the premium price tag. Powered by a reliable Yanmar 4TNV94L engine producing 38.1kW, it combines impressive digging force (37.7kN bucket, 28.4kN arm) with exceptional maneuverability in confined spaces. The dual variable axial piston pumps ensure responsive hydraulic performance, while the compact 1880mm transport width allows easy site-to-site mobility.
- Working Weight: 5,550 kg
- Max Digging Depth: 3,820 mm
- Max Digging Reach: 6,150 mm
- Bucket Capacity: 0.09–0.2 m³
- Engine: Yanmar 4TNV94L, water-cooled, 4-cylinder
- Hydraulic Flow: 55 L/min × 2 pumps
- Location: Kunming, Yunnan
Smart buyers choose quality pre-owned equipment. Acquire this dependable DH60-7 and reduce capital expenditure while maintaining productivity standards.
| Specifications | Value |
|---|---|
| No. | 1031830 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5550 |
| Bucket capacity (m³) | 0.09-0.2 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Yantai, Shandong Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 38.1/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Working form | Air-to-air cooling |
| Bucket digging force (kN) | 37.7 |
| Rod digging force (kN) | 28.4 |
| Maximum flow of main pump (l/min) | 55 x 2 |
| Traveling Hydraulic Circuit (Mpa) | 20.6 |
| Rotary Hydraulic Circuit (Mpa) | 21.6 |
| Main pump type | Variable axial piston pump ×2 |
| Working Hydraulic Circuit (Mpa) | 20.6 |
| Pilot pump flow (L/min) | 9.9 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880 |
| Total transport height (mm) | 2575 |
| Full cab height (mm) | 2575 |
| Minimum ground clearance (mm) | 350 |
| Back end turning radius (mm) | 1650 |
| Onboard width (mm) | 1885 |
| Total track length (mm) | 2540 |
| Track gauge (mm) | 1480 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 1880 |
| Track ground length (mm) | 1990 |
| Maximum digging radius (mm) | 6150 |
| Maximum digging depth (mm) | 3820 |
| Maximum excavation height (mm) | 5760 |
| Maximum unloading height (mm) | 4030 |
