Product Description
With a robust 6-ton working weight and powered by a Yanmar 4TNV94L engine, this 2016 Doosan DH60-7 excavator is site-ready for immediate deployment. Featuring a 3000mm boom and 1600mm rod, it delivers a bucket digging force of 37.7 kN, ideal for tough digging tasks. Its versatile 0.09-0.2 m³ bucket capacity and 28.4 kN rod digging force make it perfect for grading and demolition projects. Equipped with a water-cooled, 4-cylinder engine, the machine provides reliable performance with a rated power of 38.1 kW at 2200 rpm. The dual variable axial piston pumps ensure efficient hydraulic operations, supporting a maximum digging depth of 3820 mm and a maximum excavation height of 5760 mm. Located in 广西, this excavator is ready to tackle your next construction challenge.
| Specifications | Value |
|---|---|
| No. | 1032470 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5550 |
| Bucket capacity (m³) | 0.09-0.2 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Yantai, Shandong Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 38.1/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Working form | Air-to-air cooling |
| Bucket digging force (kN) | 37.7 |
| Rod digging force (kN) | 28.4 |
| Maximum flow of main pump (l/min) | 55 x 2 |
| Traveling Hydraulic Circuit (Mpa) | 20.6 |
| Rotary Hydraulic Circuit (Mpa) | 21.6 |
| Main pump type | Variable axial piston pump ×2 |
| Working Hydraulic Circuit (Mpa) | 20.6 |
| Pilot pump flow (L/min) | 9.9 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880 |
| Total transport height (mm) | 2575 |
| Full cab height (mm) | 2575 |
| Minimum ground clearance (mm) | 350 |
| Back end turning radius (mm) | 1650 |
| Onboard width (mm) | 1885 |
| Total track length (mm) | 2540 |
| Track gauge (mm) | 1480 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 1880 |
| Track ground length (mm) | 1990 |
| Maximum digging radius (mm) | 6150 |
| Maximum digging depth (mm) | 3820 |
| Maximum excavation height (mm) | 5760 |
| Maximum unloading height (mm) | 4030 |
