Product Description
Available now in Changzhou, Jiangsu, this 2018 Doosan DH70 compact excavator eliminates factory wait times and delivers immediate productivity to your project. With a 7-ton operating weight and proven Kubota V3300-DI engine producing 45.8kW at 2200rpm, this machine combines reliable performance with rapid deployment capability. Skip the lengthy procurement process—this unit is ready for fast transport to your site.
Engineered for versatility, the DH70 features a 3620mm boom and 1600mm arm configuration, delivering a maximum digging reach of 6170mm and depth of 4060mm. The 0.28m³ bucket capacity, backed by 5.3-ton digging force, handles demanding excavation tasks efficiently. Hydraulic crushing pipeline comes standard, expanding operational flexibility from day one.
- Compact footprint: 5920mm transport length, 2200mm width
- Dual travel speeds: 2.8/4.5 km/h for site maneuverability
- Water-cooled 3.318L displacement engine for sustained performance
- Located in Changzhou logistics hub for expedited regional delivery
Secure this joint-venture quality excavator today and mobilize your operations without delay.
| Specifications | Value |
|---|---|
| No. | 1008823 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 6980 |
| Bucket capacity (m³) | 0.28 |
| Boom length (mm) | 3620 |
| Rod length (mm) | 1600 |
| Country of origin | Yantai |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Kubota KubotaV3300-DI |
| Rated power (kw/rpm) | 45.8/2200 |
| Cooling mode | water-cooling |
| Displacement (L) | 3.318 |
| Working form | Fuel consumption is 163g/ps.hr |
| Rotation speed (rpm) | 10.5 |
| Bucket digging force (kN) | 5.3ton |
| Rod digging force (kN) | 3.7ton |
| Travel speed (km/h) | 2.8/4.5 |
| Maximum flow of main pump (l/min) | 162.8 |
| Traveling Hydraulic Circuit (Mpa) | 250 |
| Rotary Hydraulic Circuit (Mpa) | 190 |
| Hydraulic crushing pipeline is standard | is |
| Bucket cylinders - Number × diameter × stroke (mm) | 85*55*715 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 95*60*850 |
| Boom cylinders - Number × diameter × stroke (mm) | 110*65*865 |
| Total transport length (mm) | 5920 |
| Total transport width (mm) | 2200 |
| Total transport height (mm) | 2585 |
| Full cab height (mm) | 2585 |
| Counterweight ground clearance (mm) | 764 |
| Back end turning radius (mm) | 1710 |
| Total track length (mm) | 2568 |
| Track gauge (mm) | 1650 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2050 |
| Track ground length (mm) | 1990 |
| Maximum digging radius (mm) | 6170 |
| Maximum digging depth (mm) | 4060 |
| Maximum excavation height (mm) | 6918 |
| Maximum unloading height (mm) | 5032 |
