Product Description
Available now from our Hubei facility, this 2016 Doosan DH80 mini excavator eliminates factory lead times and accelerates your project timeline. Powered by a reliable Kubota V3300-DI engine delivering 45.8kW at 2200rpm, this 8-ton machine combines proven performance with immediate deployment capability. Water-cooled efficiency and fuel consumption of just 163g/ps.hr keep operating costs predictable across extended shifts.
Engineered for versatility, the DH80 delivers a maximum digging depth of 4,060mm and digging radius of 6,170mm. Hydraulic crushing pipeline comes standard, expanding jobsite applications without delay. Compact dimensions—5,920mm transport length and 2,200mm width—ensure fast mobilization through congested urban environments or tight access points.
- Working weight: 7,830kg with 0.28-0.32m³ bucket capacity
- Bucket digging force: 55kN / Rod digging force: 38kN
- Main pump flow: 162.8 l/min for responsive hydraulics
- Track width: 400mm for stable operation on varied terrain
- Ready for immediate shipment from Hubei—skip months of factory wait times
Fast-track your equipment acquisition. Contact our team today for expedited logistics coordination.
| Specifications | Value |
|---|---|
| No. | 1026452 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7830 |
| Bucket capacity (m³) | 0.28-0.32 |
| Boom length (mm) | 3100 |
| Rod length (mm) | 1800 |
| Country of origin | Yantai, Shandong Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Kubota KubotaV3300-DI |
| Rated power (kw/rpm) | 45.8/2200 |
| Cooling mode | water-cooling |
| Displacement (L) | 3.318 |
| Working form | Fuel consumption is 163g/ps.hr |
| Bucket digging force (kN) | 55 |
| Rod digging force (kN) | 38 |
| Maximum flow of main pump (l/min) | 162.8 |
| Traveling Hydraulic Circuit (Mpa) | 250 |
| Rotary Hydraulic Circuit (Mpa) | 190 |
| Hydraulic crushing pipeline is standard | is |
| Bucket cylinders - Number × diameter × stroke (mm) | 85*55*715 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 95*60*850 |
| Boom cylinders - Number × diameter × stroke (mm) | 110*65*865 |
| Total transport length (mm) | 5920 |
| Total transport width (mm) | 2200 |
| Total transport height (mm) | 2585 |
| Full cab height (mm) | 2585 |
| Counterweight ground clearance (mm) | 764 |
| Back end turning radius (mm) | 1710 |
| Total track length (mm) | 2568 |
| Track gauge (mm) | 1650 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2050 |
| Track ground length (mm) | 1990 |
| Maximum digging radius (mm) | 6170 |
| Maximum digging depth (mm) | 4060 |
| Maximum excavation height (mm) | 6918 |
| Maximum unloading height (mm) | 5032 |
