Product Description
Ready to deploy from 贵州, this 2016 Doosan DH80 mini excavator eliminates factory wait times and gets your project moving now. Powered by a reliable Kubota V3300-DI engine delivering 45.8kW at 2200rpm, this 8-ton workhorse combines compact dimensions (5920mm transport length, 2200mm width) with impressive reach—6170mm maximum digging radius and 4060mm digging depth. Hydraulic performance is robust: 162.8 L/min main pump flow, 55kN bucket digging force, and standard crushing pipeline capability handle demanding applications across construction and excavation sites.
- Available Now: Skip lead times—inspect and ship directly from 贵州
- Compact Power: 7830kg working weight with 0.28-0.32m³ bucket capacity
- Proven Reliability: Water-cooled Kubota engine, fuel-efficient at 163g/ps.hr
- Versatile Reach: 3100mm boom, 1800mm arm, 6918mm max digging height
- Work-Ready Hydraulics: 250MPa travel circuit, 190MPa swing circuit
Fast deployment to your site means faster ROI. Secure this Doosan DH80 today and put productive capacity to work tomorrow.
| Specifications | Value |
|---|---|
| No. | 1032761 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7830 |
| Bucket capacity (m³) | 0.28-0.32 |
| Boom length (mm) | 3100 |
| Rod length (mm) | 1800 |
| Country of origin | Yantai, Shandong Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Kubota KubotaV3300-DI |
| Rated power (kw/rpm) | 45.8/2200 |
| Cooling mode | water-cooling |
| Displacement (L) | 3.318 |
| Working form | Fuel consumption is 163g/ps.hr |
| Bucket digging force (kN) | 55 |
| Rod digging force (kN) | 38 |
| Maximum flow of main pump (l/min) | 162.8 |
| Traveling Hydraulic Circuit (Mpa) | 250 |
| Rotary Hydraulic Circuit (Mpa) | 190 |
| Hydraulic crushing pipeline is standard | is |
| Bucket cylinders - Number × diameter × stroke (mm) | 85*55*715 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 95*60*850 |
| Boom cylinders - Number × diameter × stroke (mm) | 110*65*865 |
| Total transport length (mm) | 5920 |
| Total transport width (mm) | 2200 |
| Total transport height (mm) | 2585 |
| Full cab height (mm) | 2585 |
| Counterweight ground clearance (mm) | 764 |
| Back end turning radius (mm) | 1710 |
| Total track length (mm) | 2568 |
| Track gauge (mm) | 1650 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2050 |
| Track ground length (mm) | 1990 |
| Maximum digging radius (mm) | 6170 |
| Maximum digging depth (mm) | 4060 |
| Maximum excavation height (mm) | 6918 |
| Maximum unloading height (mm) | 5032 |
