Product Description
Built for demanding job sites, this 2012 Doosan DL300 wheel loader delivers reliable performance with its WP6G125E332 engine producing 92kW at 2200rpm. Operators benefit from exceptional visibility and precise control, essential for efficient material handling in construction and aggregate operations. With a 3000kg rated load capacity and 100kN digging force, this machine tackles heavy-duty tasks while maintaining excellent stability.
Key specifications include:
- Rated Load: 3000kg with 100kN lifting force
- Operating Weight: 10,140kg for superior stability
- Maximum Unloading Height: 2960mm
- Fuel Capacity: 190L for extended operation
- Maximum Speed: 39.5km/h
- Climbing Ability: 30° gradient capability
- Compact Dimensions: 7008mm (L) × 2520mm (W) × 3222mm (H)
Equipped with a 2850mm wheelbase and 38° steering angle, this loader provides maneuverability in confined spaces while the 371.5mm ground clearance handles rough terrain effectively. Currently located in Hebei, China, this wheel loader represents proven Doosan engineering at an accessible price point.
| Specifications | Value |
|---|---|
| No. | 1011693 |
| Engine type | WP6G125E332 |
| Rated power (kw/rpm) | 92/2200 |
| Maximum torque (N.m) | 540/1400~1600 |
| Bucket capacity (m³) | |
| Rated load (tons) | |
| Rated load (kg) | 3000 |
| Digging force (lifting force) (kN) | 100 |
| Machine operating weight (kg) | 10140 |
| Max - Unloading height (mm) | 2960 |
| Unloading distance (mm) | 1040 |
| Maximum tractive force (kN) | 100 |
| Maximum climbing ability (°) | 30 |
| Fuel Tank (L) | 190 |
| Hydraulic Tank (L) | 100 |
| Engine Oil (L) | 18 |
| Wheelbase (mm) | 2850 |
| Wheel base (mm) | 1850 |
| Minimum ground clearance (mm) | 371.5 |
| Machine length (mm) | 7008 |
| Machine width (mm) | 2520 |
| Machine height (mm) | 3222 |
| Steering Angle | 38 |
| Turning radius - Outside of bucket (mm) | 5950 |
| Ternary sum (s) | 9.2 |
| Maximum speed (km/h) | 39.5 |
