Product Description
Engineered for demanding industrial applications, this 2014 Doosan DL300 wheel loader delivers robust performance through its WP6G125E332 engine, generating 92kW at 2200 rpm with a maximum torque of 540 N.m. The hydraulic system provides exceptional digging force of 100kN, matched by an equally impressive maximum tractive force of 100kN, ensuring superior material handling capabilities across varied terrain.
Built on a proven platform, this model demonstrates Doosan's commitment to engineering excellence through its well-balanced design. With an operating weight of 10,140kg and a 3,000kg rated load capacity, the machine maintains optimal stability while achieving a maximum unloading height of 2,960mm. The compact wheelbase of 2,850mm combined with a tight turning radius of 5,950mm enables maneuverability in confined spaces without compromising power delivery.
- Maximum climbing ability: 30° for challenging gradients
- Ternary sum: 9.2 seconds for rapid cycle times
- Top speed: 39.5 km/h for efficient site mobility
- Fuel capacity: 190L for extended operation
- Currently located in Zhejiang Province
This unit represents reliable Chinese-market specification equipment, des
| Specifications | Value |
|---|---|
| No. | 1006796 |
| Engine type | WP6G125E332 |
| Rated power (kw/rpm) | 92/2200 |
| Maximum torque (N.m) | 540/1400~1600 |
| Bucket capacity (m³) | |
| Rated load (tons) | |
| Rated load (kg) | 3000 |
| Digging force (lifting force) (kN) | 100 |
| Machine operating weight (kg) | 10140 |
| Max - Unloading height (mm) | 2960 |
| Unloading distance (mm) | 1040 |
| Maximum tractive force (kN) | 100 |
| Maximum climbing ability (°) | 30 |
| Fuel Tank (L) | 190 |
| Hydraulic Tank (L) | 100 |
| Engine Oil (L) | 18 |
| Wheelbase (mm) | 2850 |
| Wheel base (mm) | 1850 |
| Minimum ground clearance (mm) | 371.5 |
| Machine length (mm) | 7008 |
| Machine width (mm) | 2520 |
| Machine height (mm) | 3222 |
| Steering Angle | 38 |
| Turning radius - Outside of bucket (mm) | 5950 |
| Ternary sum (s) | 9.2 |
| Maximum speed (km/h) | 39.5 |
