Product Description
Proven performance meets robust engineering in this 2014 Doosan DL300 wheel loader, a machine that continues to demonstrate exceptional reliability in demanding work environments. Powered by a WP6G125E332 engine delivering 92kW at 2200rpm and 540N.m of torque, this workhorse handles heavy-duty applications with consistent efficiency. With a rated load capacity of 3000kg and impressive 100kN digging force, it tackles material handling tasks with authority.
Built to last through years of rigorous operation, this DL300 showcases Doosan's commitment to durability. Key specifications include:
- Operating weight: 10,140kg for optimal stability
- Maximum unloading height: 2960mm with 1040mm reach
- 30-degree climbing capability and 100kN tractive force
- 5950mm turning radius for maneuverability in confined spaces
- Maximum speed of 39.5km/h for efficient site navigation
- 190L fuel capacity supporting extended operation cycles
Currently located in Hunan, this proven wheel loader represents a dependable investment for contractors seeking reliable performance without compromise. Its decade of service validates the quality engineering behind every component.
| Specifications | Value |
|---|---|
| No. | 994572 |
| Engine type | WP6G125E332 |
| Rated power (kw/rpm) | 92/2200 |
| Maximum torque (N.m) | 540/1400~1600 |
| Bucket capacity (m³) | |
| Rated load (tons) | |
| Rated load (kg) | 3000 |
| Digging force (lifting force) (kN) | 100 |
| Machine operating weight (kg) | 10140 |
| Max - Unloading height (mm) | 2960 |
| Unloading distance (mm) | 1040 |
| Maximum tractive force (kN) | 100 |
| Maximum climbing ability (°) | 30 |
| Fuel Tank (L) | 190 |
| Hydraulic Tank (L) | 100 |
| Engine Oil (L) | 18 |
| Wheelbase (mm) | 2850 |
| Wheel base (mm) | 1850 |
| Minimum ground clearance (mm) | 371.5 |
| Machine length (mm) | 7008 |
| Machine width (mm) | 2520 |
| Machine height (mm) | 3222 |
| Steering Angle | 38 |
| Turning radius - Outside of bucket (mm) | 5950 |
| Ternary sum (s) | 9.2 |
| Maximum speed (km/h) | 39.5 |
