Product Description
With a rated load of 3,000 kg and powered by a WP6G125E332 engine, this 2016 Doosan DL300 loader ensures robust performance. Operating at 92 kW, it delivers a maximum torque of 540 N.m, providing the strength needed for demanding tasks. The machine's operating weight of 10,140 kg enhances stability, while its 30° maximum climbing ability and 371.5 mm ground clearance ensure versatility across various terrains.
- Max unloading height of 2,960 mm and an unloading distance of 1,040 mm
- Equipped with a 190 L fuel tank and 100 L hydraulic tank for extended operation
- Steering angle of 38° and a turning radius of 5,950 mm for agile maneuverability
- Cabin designed for superior visibility, enhancing operator safety and efficiency
| Specifications | Value |
|---|---|
| No. | 1014425 |
| Engine type | WP6G125E332 |
| Rated power (kw/rpm) | 92/2200 |
| Maximum torque (N.m) | 540/1400~1600 |
| Bucket capacity (m³) | |
| Rated load (tons) | |
| Rated load (kg) | 3000 |
| Digging force (lifting force) (kN) | 100 |
| Machine operating weight (kg) | 10140 |
| Max - Unloading height (mm) | 2960 |
| Unloading distance (mm) | 1040 |
| Maximum tractive force (kN) | 100 |
| Maximum climbing ability (°) | 30 |
| Fuel Tank (L) | 190 |
| Hydraulic Tank (L) | 100 |
| Engine Oil (L) | 18 |
| Wheelbase (mm) | 2850 |
| Wheel base (mm) | 1850 |
| Minimum ground clearance (mm) | 371.5 |
| Machine length (mm) | 7008 |
| Machine width (mm) | 2520 |
| Machine height (mm) | 3222 |
| Steering Angle | 38 |
| Turning radius - Outside of bucket (mm) | 5950 |
| Ternary sum (s) | 9.2 |
| Maximum speed (km/h) | 39.5 |
