Product Description
Engineered for demanding jobsites, this 2022 Doosan DL300 wheel loader delivers exceptional operator control and productivity. Powered by a WP6G125E332 engine producing 92kW at 2200 rpm with 540 N·m of torque, this machine handles a 3000kg rated load with confidence. The 100kN digging force and maximum tractive force ensure consistent performance across varied terrain, while the 30-degree climbing ability tackles challenging grades with ease.
Operator-focused design enhances daily performance through superior visibility and intuitive handling. The compact 2850mm wheelbase combined with a 5950mm turning radius provides excellent maneuverability in confined spaces. A 38-degree steering angle enables precise positioning, while the 371.5mm ground clearance maintains stability on uneven surfaces. The spacious cabin offers commanding sightlines to the 2960mm unloading height, allowing operators to work efficiently throughout extended shifts.
- Operating weight: 10,140kg for optimal stability
- Maximum speed: 39.5 km/h for efficient site mobility
- Fuel capacity: 190L for extended operation
- Location: Shaoxing, Zhejiang
| Specifications | Value |
|---|---|
| No. | 993426 |
| Engine type | WP6G125E332 |
| Rated power (kw/rpm) | 92/2200 |
| Maximum torque (N.m) | 540/1400~1600 |
| Bucket capacity (m³) | |
| Rated load (tons) | |
| Rated load (kg) | 3000 |
| Digging force (lifting force) (kN) | 100 |
| Machine operating weight (kg) | 10140 |
| Max - Unloading height (mm) | 2960 |
| Unloading distance (mm) | 1040 |
| Maximum tractive force (kN) | 100 |
| Maximum climbing ability (°) | 30 |
| Fuel Tank (L) | 190 |
| Hydraulic Tank (L) | 100 |
| Engine Oil (L) | 18 |
| Wheelbase (mm) | 2850 |
| Wheel base (mm) | 1850 |
| Minimum ground clearance (mm) | 371.5 |
| Machine length (mm) | 7008 |
| Machine width (mm) | 2520 |
| Machine height (mm) | 3222 |
| Steering Angle | 38 |
| Turning radius - Outside of bucket (mm) | 5950 |
| Ternary sum (s) | 9.2 |
| Maximum speed (km/h) | 39.5 |
