Product Description

Strengthen your fleet with this reliable 2021 Doosan DL305 wheel loader, currently located in Jiangxi. Powered by a 92kW engine and equipped with a 1.7m³ bucket capacity, this 3-ton rated load machine delivers consistent performance across demanding jobsites. With 98kN of digging force and a maximum tractive force of 100kN, it handles material loading and stockpile management with proven efficiency.

Operating at 10,500kg, this loader provides the stability contractors need for extended shifts. Key specifications include a 2,910mm maximum unloading height, 5,710mm turning radius, and impressive 9.9-second ternary cycle time. The 150L fuel tank supports longer operational periods between refueling, while the 30-degree climbing ability ensures versatility across varied terrain.

  • Rated Power: 92kW at 2,200 RPM
  • Bucket Capacity: 1.7m³
  • Rated Load: 3,000kg
  • Operating Weight: 10,500kg
  • Maximum Speed: 36 km/h
  • Hydraulic Pressure: 170/140 bars

Add proven capacity to your equipment roster. This DL305 serves as an ideal backup unit or primary loader for mid-sized operations requiring dependable material handling capabilities.

SpecificationsValue
No.1007678
Engine type
Rated power (kw/rpm)92/2200
Bucket capacity (m³)1.7
Rated load (tons)
Rated load (kg)3000
Digging force (lifting force) (kN)98
Machine operating weight (kg)10500
Max - Unloading height (mm)2910
Unloading distance (mm)1120
Maximum tractive force (kN)100
Maximum climbing ability (°)30
Fuel Tank (L)150
Hydraulic Tank (L)127
Wheelbase (mm)2830
Wheel base (mm)1850
Minimum ground clearance (mm)350
Machine length (mm)6950
Machine width (mm)2496
Machine height (mm)3280
Steering Angle40
Minimum turning radius of outer wheel center line5250
Turning radius - Outside of bucket (mm)5710
Flow rated speed (l/min)
Rated working pressure (bars)170/140
Lift (s)5.5
Unloading (s)1.2
Lower empty bucket (s)3.3
Ternary sum (s)9.9
Gearbox brand and model
Speed 4 (km/h)36/27
see more

Overview

No.1007678

Brand Name:

Doosan

Model Number:

DL305

Year:

2021

Location:

Jiangxi China

Pub Date:
