Product Description
Maximize your operational budget with this 2022 Doosan DL305 wheel loader, currently located in Huizhou, Guangdong. Delivering 92kW of rated power and a robust 3,000kg rated load capacity, this machine offers exceptional performance at a fraction of new equipment costs. Built for demanding applications, it features a 1.7m³ bucket capacity and impressive 98kN digging force, ensuring productivity across diverse job sites.
Key specifications include:
- Operating weight: 10,500kg with superior stability
- Maximum unloading height: 2,910mm for efficient truck loading
- 100kN maximum tractive force with 30° climbing capability
- Fast cycle times: 9.9-second ternary sum for increased throughput
- 150L fuel tank and 127L hydraulic tank for extended operation
- Compact 5,710mm turning radius for maneuverability in confined spaces
Rated working pressure of 170/140 bars ensures consistent hydraulic performance, while the 36km/h top speed enhances site mobility. Smart buyers recognize the value proposition: proven Doosan reliability and high-performance capabilities without the premium price tag of new equipment. This DL305 represents an intelligent investment for contractors
| Specifications | Value |
|---|---|
| No. | 998151 |
| Engine type | |
| Rated power (kw/rpm) | 92/2200 |
| Bucket capacity (m³) | 1.7 |
| Rated load (tons) | |
| Rated load (kg) | 3000 |
| Digging force (lifting force) (kN) | 98 |
| Machine operating weight (kg) | 10500 |
| Max - Unloading height (mm) | 2910 |
| Unloading distance (mm) | 1120 |
| Maximum tractive force (kN) | 100 |
| Maximum climbing ability (°) | 30 |
| Fuel Tank (L) | 150 |
| Hydraulic Tank (L) | 127 |
| Wheelbase (mm) | 2830 |
| Wheel base (mm) | 1850 |
| Minimum ground clearance (mm) | 350 |
| Machine length (mm) | 6950 |
| Machine width (mm) | 2496 |
| Machine height (mm) | 3280 |
| Steering Angle | 40 |
| Minimum turning radius of outer wheel center line | 5250 |
| Turning radius - Outside of bucket (mm) | 5710 |
| Flow rated speed (l/min) | |
| Rated working pressure (bars) | 170/140 |
| Lift (s) | 5.5 |
| Unloading (s) | 1.2 |
| Lower empty bucket (s) | 3.3 |
| Ternary sum (s) | 9.9 |
| Gearbox brand and model | |
| Speed 4 (km/h) | 36/27 |
