Product Description
With a rated power of 210 kW and a maximum torque of 1275 N.m, the Doosan DL420 offers robust performance for demanding tasks. Available now in 浙江温州, this loader features a bucket capacity of 3.9 m³ and a rated load of 8000 kg, ensuring efficient material handling. Skip the factory lead times and deploy this machine quickly to your site. The DL420 boasts a digging force of 20 kN and a maximum speed of 40 km/h, making it ideal for fast-paced logistics operations. Equipped with a 367 L fuel tank and a 265 L hydraulic tank, it is ready for extended operational periods. Its compact design, with a wheelbase of 3500 mm, allows for maneuverability in tight spaces.
| Specifications | Value |
|---|---|
| No. | 1001543 |
| Rated power (kw/rpm) | 210 |
| Maximum torque (N.m) | 1275 |
| Bucket capacity (m³) | 3.9 |
| Rated load (tons) | |
| Rated load (kg) | 8000 |
| Digging force (lifting force) (kN) | 20 |
| Machine operating weight (kg) | 21900 |
| Max - Unloading height (mm) | 3085 |
| Unloading distance (mm) | 1285 |
| Maximum tractive force (kN) | 21.4 |
| Fuel Tank (L) | 367 |
| Hydraulic Tank (L) | 265 |
| Wheelbase (mm) | 3500 |
| Machine length (mm) | 8890 |
| Machine width (mm) | 3040 |
| Machine height (mm) | 3535 |
| Turning radius - Outside of bucket (mm) | 6875 |
| Maximum speed (km/h) | 40 |
