Product Description
Expand your operational capacity with this 2016 Doosan DX215-9C excavator, currently located in Hangzhou, Zhejiang. Built for contractors managing multiple job sites, this 21-ton machine delivers consistent performance as a fleet addition or reliable backup unit. Powered by a DL06 engine producing 115 kW at 1900 rpm, it combines proven joint venture engineering with the durability demanded by high-volume operations.
Key specifications include:
- Operating weight: 20,600 kg with 0.92 m³ bucket capacity
- Maximum digging reach of 9,873 mm and depth of 6,592 mm
- Dual variable piston pumps delivering 2 × 191 L/min flow
- Bucket digging force: 136.2 kN; stick digging force: 98 kN
- 400L fuel tank and 195L hydraulic reservoir for extended shifts
- Compact transport dimensions: 9,506 mm × 2,800 mm × 2,891 mm
With a 5,700 mm boom and 2,900 mm stick configuration, this excavator handles trenching, loading, and site preparation with efficiency. Rotation speed of 9.8 rpm ensures smooth cycle times, while the 600 mm track plates provide stability across varied terrain. Ready to integrate seamlessly into existing fleets requiring proven mid-size excavation capability.
| Specifications | Value |
|---|---|
| No. | 1008927 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 20600 |
| Bucket capacity (m³) | 0.92 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | DL06 |
| Rated power (kw/rpm) | 115/1900 |
| Cylinder diameter × stroke (mm) | 100 x 125 |
| Number of cylinders (PCS) | 6 |
| Ground specific pressure (Kpa) | 45.8 |
| Rotation speed (rpm) | 9.8 |
| Bucket digging force (kN) | 136.2 |
| Rod digging force (kN) | 98 |
| Travel speed (km/h) | 5.3 / 2.9 |
| Maximum flow of main pump (l/min) | 2 x 191 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 26.5 |
| Main pump type | Variable piston pump |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot pump flow (L/min) | 32 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-115*80*1060 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-135*95*1450 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-120*85*1263 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 195 |
| Engine Oil changes (L) | 27 |
| Total transport length (mm) | 9506 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2891 |
| Full cab height (mm) | 2985 |
| Counterweight ground clearance (mm) | 1096 |
| Minimum ground clearance (mm) | 475 |
| Minimum turning radius of front working device (mm) | 3560 |
| Back end turning radius (mm) | 2794 |
| Onboard width (mm) | 2709 |
| Total track length (mm) | 4060 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3610 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 9873 |
| Maximum digging depth (mm) | 6592 |
| Maximum excavation height (mm) | 9616 |
| Maximum unloading height (mm) | 6830 |
| Maximum vertical digging depth (mm) | 3929 |
| Maximum excavation radius of stop surface (mm) | 9699 |
| Maximum effective digging depth (mm) | 6411 |
