Product Description
Featuring a robust 22-ton working weight, the Doosan DX225LC, located in Zhejiang, Hangzhou, is equipped with a powerful Doosan DL06 engine, delivering 157 kW at 1900 rpm. With a bucket capacity of 1.05 m³ and a maximum digging depth of 6630 mm, this excavator ensures efficient and precise performance on any job site.
- Enhanced operator comfort with a full cab height of 3000 mm and excellent visibility
- Stable and reliable operation, thanks to a ground specific pressure of 0.45 Kpa and a climbing ability of up to 35 degrees
- Variable axial plunger pump and gear pump system for smooth and responsive hydraulic control
- Travel speed options of 3.0 km/h and 5.5 km/h, providing flexibility for different terrains
- Water-cooled engine for consistent performance in various climates
| Specifications | Value |
|---|---|
| No. | 1001048 |
| Tonnage (tons) | 22 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 1.05 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 2900(2400,3500 optional) |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Doosan Doosan DL06 |
| Rated power (kw/rpm) | 157/1900 |
| Cooling mode | water-cooling |
| Ground specific pressure (Kpa) | 0.45 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 35 degrees |
| Bucket digging force (kN) | 136.2(144.1) |
| Rod digging force (kN) | 102.9(116.6/94.1) |
| Travel speed (km/h) | 3.0/5.5 |
| Main overflow set pressure (Mpa) | 330 |
| Maximum flow of main pump (l/min) | 215 x 2 |
| Rotary Hydraulic Circuit (Mpa) | 281 |
| Main pump type | Variable axial plunger pump ×2+ gear pump |
| Fuel Tank (L) | 400 |
| Total transport length (mm) | 9510 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3030 |
| Full cab height (mm) | 3000 |
| Counterweight ground clearance (mm) | 1105 |
| Minimum ground clearance (mm) | 480 |
| Back end turning radius (mm) | 2750 |
| Total track length (mm) | 4440 |
| Track gauge (mm) | 2390 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2990 |
| Track ground length (mm) | 3645 |
| Maximum digging radius (mm) | 9910(9580/10445) |
| Maximum digging depth (mm) | 6630(6125/7230) |
| Maximum excavation height (mm) | 9660(9825/9870) |
| Maximum unloading height (mm) | 6810(6885/7020) |
| Maximum vertical digging depth (mm) | 6045(6035/6560) |
| Bulldozer lift or depth (mm) | No dodging plate |
| Maximum excavation radius of stop surface (mm) | |9735(9400/10230) |
| Maximum effective digging depth (mm) | |6445(5930/7070) |
