Product Description
Expand your operational capacity with this 2022 Doosan DX230LC excavator, a proven 23-ton workhorse engineered for contractors managing multiple jobsites simultaneously. Powered by the reliable Doosan DL06 engine delivering 116kW at 1900rpm, this Korean-built machine integrates seamlessly into existing fleets requiring consistent performance and minimal downtime. Currently located in Sichuan, it offers immediate deployment capability.
Key specifications include:
- 1.05m³ bucket capacity with 152kN digging force for high-productivity earthmoving
- 9,900mm maximum reach and 6,620mm digging depth across varied applications
- 5,700mm boom and 2,900mm arm (alternative lengths available: 2,400mm/3,500mm)
- 400L fuel tank supporting extended operating shifts
- 2,750mm rear swing radius for confined-space maneuverability
- 35-degree climbing ability and 0.45kPa ground pressure for challenging terrain
With 21,500kg operating weight and transport dimensions of 9,485mm × 2,990mm × 3,005mm, this DX230LC matches standard lowbed requirements. Fleet managers gain parts commonality, operator familiarity, and proven Korean engineering—critical factors when scaling operations or cov
| Specifications | Value |
|---|---|
| No. | 1031664 |
| Tonnage (tons) | 23 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 1.05 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 2900(2400,3500 optional) |
| Country of origin | Korea |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Doosan Doosan DL06 |
| Rated power (kw/rpm) | 116/1900 |
| Ground specific pressure (Kpa) | 0.45 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 35 degrees |
| Bucket digging force (kN) | 152/143 |
| Rod digging force (kN) | 108/102 |
| Travel speed (km/h) | 3.0/5.5 |
| Main overflow set pressure (Mpa) | 330 |
| Fuel Tank (L) | 400 |
| Total transport length (mm) | 9485 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3005 |
| Full cab height (mm) | 2975 |
| Counterweight ground clearance (mm) | 1055 |
| Minimum ground clearance (mm) | 480 |
| Back end turning radius (mm) | 2750 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2390 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2990 |
| Track ground length (mm) | 3650 |
| Maximum digging radius (mm) | 9900(9480/10340) |
| Maximum digging depth (mm) | 6620(6110/7220) |
| Maximum excavation height (mm) | 9750(9630/9870) |
| Maximum unloading height (mm) | 6990(6830/7150) |
| Bulldozer lift or depth (mm) | No dodging plate |
