Product Description
Built in 2016 and stationed in Hunan, this Doosan DX260LC excavator delivers 180 kW of proven Doosan DE08TIS power—ideal for contractors seeking reliable fleet capacity without downtime risk. Operating at 24,800 kg working weight with a 1.2 m³ bucket, this 25-ton workhorse tackles digging depths to 6,826 mm and reaches 10,207 mm horizontally, matching the productivity of newer units at a fraction of the acquisition cost.
- Fleet-Ready Performance: 172.6 kN bucket digging force and dual 219 L/min variable piston pumps maintain pace with demanding schedules
- Operational Efficiency: 450 L fuel tank and 5.2 km/h travel speed minimize refueling stops and site-to-site transit delays
- Versatile Reach: Multiple rod configurations (3000/2500/3500 mm) adapt to excavation, trenching, and loading applications across diverse jobsites
- Proven Reliability: Joint venture manufacturing standards and 6-cylinder water-cooled engine ensure consistent uptime for backup or parallel deployment
Add proven capacity to your operation. This DX260LC integrates seamlessly into existing Doosan fleets or provides immediate capability expansion fo
| Specifications | Value |
|---|---|
| No. | 1022479 |
| Tonnage (tons) | 25 |
| Working weight (kg) | 24800 |
| Bucket capacity (m³) | 1.2 |
| Boom length (mm) | 5900 |
| Rod length (mm) | 3000/2500/3500 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Doosan DE08TIS |
| Rated power (kw/rpm) | 180 / 1900 |
| Maximum torque (N.m) | 78/1400 |
| Number of cylinders (PCS) | 6 |
| Working form | 4-stroke, water-cooled, direct spray |
| Ground specific pressure (Kpa) | 46.1 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 172.6 / 182.4 |
| Rod digging force (kN) | 114.7 / 121.6 |
| Travel speed (km/h) | 5.2 / 3.1 |
| Turning torque (Nm) | 78 |
| Maximum flow of main pump (l/min) | 2 x 219 |
| Traveling Hydraulic Circuit (Mpa) | 32.4 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Variable piston pump |
| Working Hydraulic Circuit (Mpa) | 32.4 |
| Fuel Tank (L) | 450 |
| Hydraulic Tank (L) | 240 |
| Total transport length (mm) | 10055 |
| Total transport width (mm) | 3200 |
| Total transport height (mm) | 3100 |
| Full cab height (mm) | 2970(to top of cab) |
| Counterweight ground clearance (mm) | 1110 |
| Minimum ground clearance (mm) | 450 |
| Back end turning radius (mm) | 2995 |
| Total track length (mm) | 4625 |
| Track gauge (mm) | 2600 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3200 |
| Track ground length (mm) | 3835 |
| Maximum digging radius (mm) | 10207 |
| Maximum digging depth (mm) | 6826 |
| Maximum excavation height (mm) | 9820 |
| Maximum unloading height (mm) | 6925 |
| Maximum vertical digging depth (mm) | 6258 |
| Bulldozer lift or depth (mm) | There is no |
