Product Description
Ready to deploy from 山东济南, this 2019 Doosan DX520LC-9C eliminates factory wait times and gets your 52-ton excavator on-site fast. Powered by a robust DC13 engine delivering 257 kW at 1800 rpm, this machine combines proven reliability with immediate availability. Skip the lead times—this backhoe is available now for rapid mobilization to your project.
- Operating Weight: 50,800 kg with 2.72–3.2 m³ bucket capacity
- Digging Performance: 10,765 mm maximum reach, 6,765 mm depth, bucket force up to 282.2 kN
- Hydraulic System: Dual variable axial piston pumps (2×355 L/min) for efficient cycle times
- Mobility: 5.3 km/h travel speed, 8.3 rpm rotation for productive positioning
- Logistics: Transport dimensions 11,530×3,340×4,125 mm—ready for immediate shipment
Stationed in Jinan, Shandong Province, this joint-venture manufactured excavator offers quick access to major infrastructure corridors across China and international ports. Secure proven heavy-duty performance without the downtime of new equipment procurement. Contact us today for fast-track delivery to your construction site.
| Specifications | Value |
|---|---|
| No. | 1037759 |
| Tonnage (tons) | 52 |
| Working weight (kg) | 50800 |
| Bucket capacity (m³) | 2.72~3.2 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | DC13 |
| Rated power (kw/rpm) | 257/1800 |
| Cylinder diameter × stroke (mm) | 130*160 |
| Number of cylinders (PCS) | 6 |
| Rotation speed (rpm) | 8.3 |
| Bucket digging force (kN) | 266.6/282.2 |
| Rod digging force (kN) | 233.2/247.0 |
| Travel speed (km/h) | 5.3/3.1 |
| Turning torque (Nm) | 16304 |
| Maximum flow of main pump (l/min) | 2*355 |
| Traveling Hydraulic Circuit (Mpa) | 33 |
| Rotary Hydraulic Circuit (Mpa) | 30 |
| Control Hydraulic Circuit (Mpa) | 35 |
| Main pump type | Variable axial piston pump |
| Working Hydraulic Circuit (Mpa) | 33 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-170*115*1341 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-190*130*1980 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-170*115*1650 |
| Fuel Tank (L) | 626 |
| Hydraulic Tank (L) | 390 |
| Engine Oil changes (L) | 45 |
| Coolant (L) | 51 |
| Total transport length (mm) | 11530 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 4125 |
| Counterweight ground clearance (mm) | 1460 |
| Minimum ground clearance (mm) | 770 |
| Minimum turning radius of front working device (mm) | 5120 |
| Back end turning radius (mm) | 3800 |
| Total track length (mm) | 5455 |
| Track plate width (mm) | 600 |
| Number of sprockets (single side) (each) | 3 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 53 |
| Maximum digging radius (mm) | 10765 |
| Maximum digging depth (mm) | 6765 |
| Maximum excavation height (mm) | 9705 |
| Maximum unloading height (mm) | 6750 |
| Maximum excavation radius of stop surface (mm) | 10475 |
| Maximum effective digging depth (mm) | 10475 |
Overview
No.1037759
Brand Name：
DoosanModel Number：
DX520LC-9CYear：
2019
Location：
Shandong China
