Product Description
Ready to deploy from Shaoxing, Zhejiang, this 2012 Doosan DX60 compact excavator eliminates factory wait times and gets your project moving immediately. Built by a joint venture manufacturer in Yantai, this 6-ton machine combines proven Yanmar 4TNV94L engine reliability with responsive hydraulic performance—ideal for urban construction, utility work, and site preparation where space is limited.
Operating at 5,700 kg working weight with a 0.21 m³ bucket capacity, the DX60 delivers 44 kN bucket digging force and reaches 6,150 mm maximum digging radius. Powered by a 39.7 kW engine producing maximum torque at low RPM, this excavator offers 3,805 mm digging depth and 4,065 mm unloading height. Dual main pumps (60.5 l/min each) ensure smooth multi-function operation, while the compact 1,650 mm rear swing radius enables efficient work in confined areas.
Key Specifications:
- Yanmar 4TNV94L engine: 39.7 kW @ 2,200 rpm
- Maximum digging depth: 3,805 mm
- Bucket digging force: 44 kN
- Transport dimensions: 5,850 × 2,000 × 2,575 mm
- 115L fuel capacity for extended operation
- Available now—fast shipment from Zhejiang
| Specifications | Value |
|---|---|
| No. | 1014607 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5700 |
| Bucket capacity (m³) | 0.21 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Yantai |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar YANMAR 4TNV94L |
| Rated power (kw/rpm) | 39.7 / 2200 |
| Maximum torque (N.m) | 20-22/1100 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 78/30 degrees |
| Bucket digging force (kN) | 44 |
| Rod digging force (kN) | 28 |
| Maximum tractive force (kN) | 58 |
| Travel speed (km/h) | 4.1 / 3.0 |
| Turning torque (Nm) | 20 ~ 22 |
| Maximum flow of main pump (l/min) | 60.5 x 2 + 36 |
| Traveling Hydraulic Circuit (Mpa) | 21.6 |
| Working Hydraulic Circuit (Mpa) | 21.6 |
| Fuel Tank (L) | 115 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 2000 |
| Total transport height (mm) | 2575(to top of cab) |
| Minimum ground clearance (mm) | 400 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2540 |
| Maximum digging radius (mm) | 6150 |
| Maximum digging depth (mm) | 3805 |
| Maximum excavation height (mm) | 5790 |
| Maximum unloading height (mm) | 4065 |
| Maximum vertical digging depth (mm) | 3038 |
| Dodging plate width × height (mm) | 2000 x 350 |
