Product Description
Strengthen your fleet with this reliable 2016 Doosan DX60 mini excavator, currently located in Sichuan. Built at Doosan's Yantai facility, this 6-ton workhorse delivers consistent performance across residential, utility, and light commercial applications. Powered by a proven Yanmar 4TNV94L engine producing 39.7 kW at 2200 rpm, this machine combines fuel efficiency with dependable hydraulic power.
Compact dimensions make it ideal for confined jobsites while maintaining serious capability:
- Maximum digging depth of 3,805 mm and reach of 6,150 mm
- Bucket digging force of 44 kN with 0.21 m³ capacity
- Transport width of just 2,000 mm for easy mobilization
- Dual main pumps delivering 60.5 l/min each plus auxiliary 36 l/min
- Impressive 78% (30-degree) climbing ability for challenging terrain
- 115-liter fuel tank for extended operation
Operating weight of 5,700 kg provides stability without sacrificing maneuverability. Whether you need a dedicated utility machine or backup support during peak season, this DX60 integrates seamlessly into existing operations. Ready to work when your primary equipment is committed elsewhere.
| Specifications | Value |
|---|---|
| No. | 1010408 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5700 |
| Bucket capacity (m³) | 0.21 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Yantai |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar YANMAR 4TNV94L |
| Rated power (kw/rpm) | 39.7 / 2200 |
| Maximum torque (N.m) | 20-22/1100 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 78/30 degrees |
| Bucket digging force (kN) | 44 |
| Rod digging force (kN) | 28 |
| Maximum tractive force (kN) | 58 |
| Travel speed (km/h) | 4.1 / 3.0 |
| Turning torque (Nm) | 20 ~ 22 |
| Maximum flow of main pump (l/min) | 60.5 x 2 + 36 |
| Traveling Hydraulic Circuit (Mpa) | 21.6 |
| Working Hydraulic Circuit (Mpa) | 21.6 |
| Fuel Tank (L) | 115 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 2000 |
| Total transport height (mm) | 2575(to top of cab) |
| Minimum ground clearance (mm) | 400 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2540 |
| Maximum digging radius (mm) | 6150 |
| Maximum digging depth (mm) | 3805 |
| Maximum excavation height (mm) | 5790 |
| Maximum unloading height (mm) | 4065 |
| Maximum vertical digging depth (mm) | 3038 |
| Dodging plate width × height (mm) | 2000 x 350 |
