Product Description
Located in 江苏, this 2017 Doosan DX60 excavator is available now, ready for immediate deployment to your site. With a working weight of 5700 kg and a bucket capacity of 0.21 m³, it offers robust performance. Powered by a Yanmar 4TNV94L engine, delivering 39.7 kW at 2200 rpm, this model ensures reliable operation. Featuring a maximum digging depth of 3805 mm and a maximum unloading height of 4065 mm, it is ideal for various construction tasks. Skip the factory lead times and get to work faster with this versatile machine.
- Maximum digging force: 44 kN (bucket), 28 kN (rod)
- Travel speed: 4.1 / 3.0 km/h
- Total transport dimensions: 5850 x 2000 x 2575 mm
- Fuel tank capacity: 115 L
- Back end turning radius: 1650 mm
| Specifications | Value |
|---|---|
| No. | 1016466 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5700 |
| Bucket capacity (m³) | 0.21 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Yantai |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar YANMAR 4TNV94L |
| Rated power (kw/rpm) | 39.7 / 2200 |
| Maximum torque (N.m) | 20-22/1100 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 78/30 degrees |
| Bucket digging force (kN) | 44 |
| Rod digging force (kN) | 28 |
| Maximum tractive force (kN) | 58 |
| Travel speed (km/h) | 4.1 / 3.0 |
| Turning torque (Nm) | 20 ~ 22 |
| Maximum flow of main pump (l/min) | 60.5 x 2 + 36 |
| Traveling Hydraulic Circuit (Mpa) | 21.6 |
| Working Hydraulic Circuit (Mpa) | 21.6 |
| Fuel Tank (L) | 115 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 2000 |
| Total transport height (mm) | 2575(to top of cab) |
| Minimum ground clearance (mm) | 400 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2540 |
| Maximum digging radius (mm) | 6150 |
| Maximum digging depth (mm) | 3805 |
| Maximum excavation height (mm) | 5790 |
| Maximum unloading height (mm) | 4065 |
| Maximum vertical digging depth (mm) | 3038 |
| Dodging plate width × height (mm) | 2000 x 350 |
