Product Description
Engineered for precision work in confined spaces, this 2019 Doosan DX60 mini excavator delivers exceptional operator control and jobsite versatility. Powered by a reliable Yanmar 4TNV94L engine producing 39.7 kW at 2200 rpm, this 5.7-ton machine combines responsive hydraulics with stable performance across demanding terrain. The compact 2000mm transport width and 1650mm rear turning radius enable efficient maneuvering in urban environments and tight construction sites.
Operators benefit from enhanced visibility and intuitive controls within the well-designed cabin. The machine's 78% climbing ability and 400mm ground clearance ensure confident operation on uneven surfaces, while the dual main pump system (60.5 x 2 + 36 l/min) provides smooth, simultaneous multi-function operation. With a maximum digging depth of 3805mm and reach extending to 6150mm, this excavator handles trenching, foundation work, and utility installation with consistent accuracy.
- Bucket digging force: 44 kN for efficient material penetration
- 9.5 rpm rotation speed for quick positioning
- 115L fuel tank supports extended operation
- Currently located in Heze, Shandong
| Specifications | Value |
|---|---|
| No. | 1009913 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5700 |
| Bucket capacity (m³) | 0.21 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Yantai |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar YANMAR 4TNV94L |
| Rated power (kw/rpm) | 39.7 / 2200 |
| Maximum torque (N.m) | 20-22/1100 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 78/30 degrees |
| Bucket digging force (kN) | 44 |
| Rod digging force (kN) | 28 |
| Maximum tractive force (kN) | 58 |
| Travel speed (km/h) | 4.1 / 3.0 |
| Turning torque (Nm) | 20 ~ 22 |
| Maximum flow of main pump (l/min) | 60.5 x 2 + 36 |
| Traveling Hydraulic Circuit (Mpa) | 21.6 |
| Working Hydraulic Circuit (Mpa) | 21.6 |
| Fuel Tank (L) | 115 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 2000 |
| Total transport height (mm) | 2575(to top of cab) |
| Minimum ground clearance (mm) | 400 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2540 |
| Maximum digging radius (mm) | 6150 |
| Maximum digging depth (mm) | 3805 |
| Maximum excavation height (mm) | 5790 |
| Maximum unloading height (mm) | 4065 |
| Maximum vertical digging depth (mm) | 3038 |
| Dodging plate width × height (mm) | 2000 x 350 |
