Product Description
Built for demanding jobsites, this 2021 Doosan DX60 mini excavator demonstrates the proven engineering that defines the model's reputation. Operating at 6 tons with a working weight of 5,700 kg, this machine combines compact dimensions with serious capability. The Yanmar 4TNV94L engine delivers 39.7 kW of rated power, providing consistent performance across varied terrain with an impressive 78% climbing ability.
Engineered as a joint venture/import model from Yantai, this workhorse offers reliable hydraulics and robust digging force. Key specifications include:
- Maximum digging depth: 3,805 mm with 6,150 mm reach
- Bucket digging force: 44 kN; Rod digging force: 28 kN
- Dual main pump flow: 60.5 x 2 + 36 l/min
- Compact transport dimensions: 5,850 x 2,000 x 2,575 mm
- 115L fuel capacity for extended operation
Currently located in Shanghai, this DX60 represents a machine that has proven its durability through real-world application. With a 1,650 mm rear turning radius and 0.21 m³ bucket capacity, it tackles confined spaces without compromising productivity. A dependable choice for contractors seeking tested performance.
| Specifications | Value |
|---|---|
| No. | 1008697 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5700 |
| Bucket capacity (m³) | 0.21 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Yantai |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar YANMAR 4TNV94L |
| Rated power (kw/rpm) | 39.7 / 2200 |
| Maximum torque (N.m) | 20-22/1100 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 78/30 degrees |
| Bucket digging force (kN) | 44 |
| Rod digging force (kN) | 28 |
| Maximum tractive force (kN) | 58 |
| Travel speed (km/h) | 4.1 / 3.0 |
| Turning torque (Nm) | 20 ~ 22 |
| Maximum flow of main pump (l/min) | 60.5 x 2 + 36 |
| Traveling Hydraulic Circuit (Mpa) | 21.6 |
| Working Hydraulic Circuit (Mpa) | 21.6 |
| Fuel Tank (L) | 115 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 2000 |
| Total transport height (mm) | 2575(to top of cab) |
| Minimum ground clearance (mm) | 400 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2540 |
| Maximum digging radius (mm) | 6150 |
| Maximum digging depth (mm) | 3805 |
| Maximum excavation height (mm) | 5790 |
| Maximum unloading height (mm) | 4065 |
| Maximum vertical digging depth (mm) | 3038 |
| Dodging plate width × height (mm) | 2000 x 350 |
