Product Description
Secure immediate deployment with this 2022 Doosan DX60 mini excavator, currently located in Changzhou, Jiangsu and ready for dispatch. Skip months of factory lead times—this 6-ton workhorse is available now for fast mobilization to your jobsite. Powered by a reliable Yanmar 4TNV94L engine delivering 39.7 kW at 2200 rpm, this compact machine combines impressive digging force with nimble maneuverability in confined spaces.
- Operating weight: 5,700 kg with 0.21 m³ bucket capacity
- Maximum digging reach: 6,150 mm; depth: 3,805 mm
- Bucket digging force: 44 kN; rod force: 28 kN
- Compact footprint: 2,000 mm width, 1,650 mm tail swing radius
- Dual main pumps: 60.5 L/min × 2 for responsive hydraulics
- Transport-ready dimensions: 5,850 × 2,000 × 2,575 mm
Based in Changzhou's logistics hub, this excavator ships rapidly via road, rail, or port access. Ideal for urban construction, landscaping, and utility projects requiring immediate equipment availability. Contact Fair Trade Machinery today to arrange inspection and expedited delivery.
| Specifications | Value |
|---|---|
| No. | 1011589 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5700 |
| Bucket capacity (m³) | 0.21 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Yantai |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar YANMAR 4TNV94L |
| Rated power (kw/rpm) | 39.7 / 2200 |
| Maximum torque (N.m) | 20-22/1100 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 78/30 degrees |
| Bucket digging force (kN) | 44 |
| Rod digging force (kN) | 28 |
| Maximum tractive force (kN) | 58 |
| Travel speed (km/h) | 4.1 / 3.0 |
| Turning torque (Nm) | 20 ~ 22 |
| Maximum flow of main pump (l/min) | 60.5 x 2 + 36 |
| Traveling Hydraulic Circuit (Mpa) | 21.6 |
| Working Hydraulic Circuit (Mpa) | 21.6 |
| Fuel Tank (L) | 115 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 2000 |
| Total transport height (mm) | 2575(to top of cab) |
| Minimum ground clearance (mm) | 400 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2540 |
| Maximum digging radius (mm) | 6150 |
| Maximum digging depth (mm) | 3805 |
| Maximum excavation height (mm) | 5790 |
| Maximum unloading height (mm) | 4065 |
| Maximum vertical digging depth (mm) | 3038 |
| Dodging plate width × height (mm) | 2000 x 350 |
