Product Description
Built for reliability and proven in the field, this 2016 Doosan DX60-9C compact excavator delivers consistent performance across demanding jobsites. With over seven years of operational history, this 6-ton machine demonstrates Doosan's commitment to durable engineering and long-term value. Powered by a robust D24C turbocharged diesel engine producing 38.9 kW at 2100 rpm, it combines efficient fuel consumption with dependable power delivery.
Engineered for versatility, this excavator offers impressive reach capabilities with a maximum digging radius of 6,136mm and maximum digging depth of 3,807mm. The 0.21m³ backhoe bucket, reinforced by 4.2-ton bucket digging force, tackles tough excavation tasks with confidence. Compact dimensions—5,870mm transport length and 2,000mm width—enable maneuverability in confined spaces while maintaining stability through optimized ground pressure of just 30 kPa.
- Working Weight: 5,700 kg with superior balance
- Hydraulic System: Dual variable piston pumps (2 × 57.8 L/min) for smooth operation
- Travel Speed: 4.2 km/h for efficient site mobility
- Fuel Capacity: 115L tank supports extended work shifts
- Location: Shaoxing, Zhejiang—ready for global shipmen
| Specifications | Value |
|---|---|
| No. | 1016689 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5700 |
| Bucket capacity (m³) | 0.21 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | D24C DIESEL |
| Rated power (kw/rpm) | 38.9/2100 |
| Cylinder diameter × stroke (mm) | 90 x 94 |
| Number of cylinders (PCS) | 4 |
| Working form | In-line, turbocharged |
| Ground specific pressure (Kpa) | 30 |
| Rotation speed (rpm) | 9 |
| Bucket digging force (kN) | 4.2ton |
| Rod digging force (kN) | 2.8ton |
| Travel speed (km/h) | 4.2/2.3 |
| Turning torque (Nm) | 971 |
| Type of walking hydraulic motor | Axial piston hydraulic motor |
| Maximum flow of main pump (l/min) | 2 x 57.8 |
| Traveling Hydraulic Circuit (Mpa) | 240 |
| Rotary Hydraulic Circuit (Mpa) | 220 |
| Main pump type | Variable piston pump |
| Working Hydraulic Circuit (Mpa) | 240 |
| Fuel Tank (L) | 115 |
| Hydraulic System (L) | 62 |
| Total transport length (mm) | 5870 |
| Total transport width (mm) | 2000 |
| Total transport height (mm) | 1983 |
| Full cab height (mm) | 2565 |
| Counterweight ground clearance (mm) | 350 |
| Minimum ground clearance (mm) | 700 |
| Minimum turning radius of front working device (mm) | 2365 |
| Back end turning radius (mm) | 1660 |
| Onboard width (mm) | 1850 |
| Total track length (mm) | 2540 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Maximum digging radius (mm) | 6136 |
| Maximum digging depth (mm) | 3807 |
| Maximum excavation height (mm) | 5788 |
| Maximum unloading height (mm) | 4064 |
| Maximum vertical digging depth (mm) | 3037 |
| Dodging plate width × height (mm) | 2000 x 350 |
| Maximum excavation radius of stop surface (mm) | 6000 |
| Maximum effective digging depth (mm) | 3388 |
