Product Description
Built for demanding jobsites, this 2021 Doosan DX60-9C mini excavator demonstrates the engineering excellence that defines the brand's reputation. Operating at 6 tons with a working weight of 5,700 kg, this compact powerhouse delivers consistent performance through its D24C diesel engine, generating 38.9 kW at 2100 rpm. Currently located in Shaoxing, Zhejiang, this machine represents proven reliability in the field.
Engineered with a robust 4-cylinder turbocharged configuration, the DX60-9C combines a 3,000 mm boom and 1,600 mm arm to achieve a maximum digging reach of 6,136 mm and depth of 3,807 mm. The 0.21 m³ backhoe bucket, backed by 4.2-ton digging force, tackles tough excavation tasks with authority. Dual variable piston pumps delivering 2 x 57.8 l/min ensure responsive hydraulic performance across all functions.
Key specifications include:
- Maximum digging height: 5,788 mm with 4,064 mm unloading capability
- Compact transport dimensions: 5,870 mm length × 2,000 mm width
- Travel speeds: 4.2/2.3 km/h for versatile mobility
- 115L fuel capacity for extended operation
- Low ground pressure: 30 kPa for minimal site disturbance
| Specifications | Value |
|---|---|
| No. | 1008035 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5700 |
| Bucket capacity (m³) | 0.21 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | D24C DIESEL |
| Rated power (kw/rpm) | 38.9/2100 |
| Cylinder diameter × stroke (mm) | 90 x 94 |
| Number of cylinders (PCS) | 4 |
| Working form | In-line, turbocharged |
| Ground specific pressure (Kpa) | 30 |
| Rotation speed (rpm) | 9 |
| Bucket digging force (kN) | 4.2ton |
| Rod digging force (kN) | 2.8ton |
| Travel speed (km/h) | 4.2/2.3 |
| Turning torque (Nm) | 971 |
| Type of walking hydraulic motor | Axial piston hydraulic motor |
| Maximum flow of main pump (l/min) | 2 x 57.8 |
| Traveling Hydraulic Circuit (Mpa) | 240 |
| Rotary Hydraulic Circuit (Mpa) | 220 |
| Main pump type | Variable piston pump |
| Working Hydraulic Circuit (Mpa) | 240 |
| Fuel Tank (L) | 115 |
| Hydraulic System (L) | 62 |
| Total transport length (mm) | 5870 |
| Total transport width (mm) | 2000 |
| Total transport height (mm) | 1983 |
| Full cab height (mm) | 2565 |
| Counterweight ground clearance (mm) | 350 |
| Minimum ground clearance (mm) | 700 |
| Minimum turning radius of front working device (mm) | 2365 |
| Back end turning radius (mm) | 1660 |
| Onboard width (mm) | 1850 |
| Total track length (mm) | 2540 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Maximum digging radius (mm) | 6136 |
| Maximum digging depth (mm) | 3807 |
| Maximum excavation height (mm) | 5788 |
| Maximum unloading height (mm) | 4064 |
| Maximum vertical digging depth (mm) | 3037 |
| Dodging plate width × height (mm) | 2000 x 350 |
| Maximum excavation radius of stop surface (mm) | 6000 |
| Maximum effective digging depth (mm) | 3388 |
