Product Description
Engineered for precision work in confined spaces, this 2016 Doosan DX75 delivers operator-focused performance across demanding job sites. Operating at 7.35 tons with a Yanmar 4TNV94L engine producing 39.7 kW, this excavator combines responsive hydraulics with exceptional maneuverability. The compact 2,100mm transport width and tight 1,755mm rear turning radius enable efficient operation in restricted urban environments.
Operators benefit from superior visibility through the elevated cab positioned at 2,680mm, providing clear sightlines to the 6,270mm maximum digging radius. Stability remains consistent throughout the working envelope, supported by a 2,750mm track length and 1,650mm gauge configuration. The variable piston pump delivers precise control for the 0.28m³ bucket, generating 53.4 kN digging force with smooth, predictable response.
- Rotation speed: 10.7 rpm for efficient positioning
- Dual travel speeds: 3.0/4.7 km/h for versatility
- Maximum digging depth: 3,930mm
- 30° climbing capability on challenging terrain
- 111L fuel capacity for extended operation
Currently located in Lianyungang, Jiangsu, this joint-venture manufactured machine represents proven relia
| Specifications | Value |
|---|---|
| No. | 995921 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7350 |
| Bucket capacity (m³) | 0.28 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.7 / 2200 |
| Maximum torque (N.m) | 24.6/1475 |
| Number of cylinders (PCS) | 4 |
| Working form | 4-stroke, water-cooled, direct spray |
| Rotation speed (rpm) | 10.7 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 53.4 |
| Rod digging force (kN) | 36.9 |
| Travel speed (km/h) | 3.0 / 4.7 |
| Turning torque (Nm) | 23.4 ~ 24.6 |
| Main pump type | Variable piston pump |
| Fuel Tank (L) | 111 |
| Total transport length (mm) | 6030 |
| Total transport width (mm) | 2100 |
| Total transport height (mm) | 2680(to top of cab) |
| Full cab height (mm) | 2680 |
| Minimum ground clearance (mm) | 370 |
| Minimum turning radius of front working device (mm) | 1745 |
| Back end turning radius (mm) | 1755 |
| Onboard width (mm) | 2130 |
| Total track length (mm) | 2750 |
| Track gauge (mm) | 1650 |
| Track ground length (mm) | 2110 |
| Maximum digging radius (mm) | 6270 |
| Maximum digging depth (mm) | 3930 |
| Maximum excavation height (mm) | 7050 |
| Maximum unloading height (mm) | 5165 |
| Maximum vertical digging depth (mm) | 2570 |
| Dodging plate width × height (mm) | 2100 x 420 |
| Maximum excavation radius of stop surface (mm) | 6115 |
