Product Description
Engineered with Yanmar's proven 4TNV94L engine delivering 39.7 kW at 2200 rpm, this 2020 Doosan DX75 combines precision hydraulics with reliable Japanese powertrain technology. The variable piston pump system drives impressive digging forces—53.4 kN bucket force and 36.9 kN arm force—making it highly capable in demanding excavation applications across its 7-ton weight class.
Built as a joint venture model in Yantai, China, this machine demonstrates Doosan's commitment to engineering excellence through its compact yet powerful design. With a maximum digging reach of 6,270 mm and depth capacity of 3,930 mm, the DX75 offers exceptional working range for its size. The 0.28 m³ bucket capacity, paired with 10.7 rpm rotation speed and 30° climbing ability, ensures productive performance in confined jobsites.
Key technical specifications include:
- Working weight: 7,350 kg with 111L fuel capacity
- Compact transport dimensions: 6,030 mm (L) × 2,100 mm (W) × 2,680 mm (H)
- Dual travel speeds: 3.0/4.7 km/h for versatile mobility
- 370 mm ground clearance with 2,110 mm track contact length
Currently located in Shaoxing, Zhejiang, this unit represents proven mid-size excavator techn
| Specifications | Value |
|---|---|
| No. | 1021118 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7350 |
| Bucket capacity (m³) | 0.28 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.7 / 2200 |
| Maximum torque (N.m) | 24.6/1475 |
| Number of cylinders (PCS) | 4 |
| Working form | 4-stroke, water-cooled, direct spray |
| Rotation speed (rpm) | 10.7 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 53.4 |
| Rod digging force (kN) | 36.9 |
| Travel speed (km/h) | 3.0 / 4.7 |
| Turning torque (Nm) | 23.4 ~ 24.6 |
| Main pump type | Variable piston pump |
| Fuel Tank (L) | 111 |
| Total transport length (mm) | 6030 |
| Total transport width (mm) | 2100 |
| Total transport height (mm) | 2680(to top of cab) |
| Full cab height (mm) | 2680 |
| Minimum ground clearance (mm) | 370 |
| Minimum turning radius of front working device (mm) | 1745 |
| Back end turning radius (mm) | 1755 |
| Onboard width (mm) | 2130 |
| Total track length (mm) | 2750 |
| Track gauge (mm) | 1650 |
| Track ground length (mm) | 2110 |
| Maximum digging radius (mm) | 6270 |
| Maximum digging depth (mm) | 3930 |
| Maximum excavation height (mm) | 7050 |
| Maximum unloading height (mm) | 5165 |
| Maximum vertical digging depth (mm) | 2570 |
| Dodging plate width × height (mm) | 2100 x 420 |
| Maximum excavation radius of stop surface (mm) | 6115 |
