Product Description
With a working weight of 7900 kg and an 8-ton capacity, the Doosan DX80 is equipped to handle demanding tasks. Powered by a Yanmar 4TNV98 VDB24 engine, this 2016 model delivers 41.4 kW at 2100 rpm, ensuring robust performance. Located in 福建福州, it stands as an ideal fleet addition for contractors looking to enhance their operational flexibility.
- Bucket capacity ranges from 0.30 to 0.32 m³, suitable for various excavation needs.
- Maximum digging depth of 4165 mm and maximum digging radius of 6350 mm provide extensive reach.
- Travel speed up to 4.9 km/h and climbing ability of 30° make it versatile across different terrains.
- Total transport dimensions (6000 x 2290 x 2685 mm) ensure easy relocation and setup.
Integrate this reliable and efficient excavator into your fleet to maintain productivity and meet tight deadlines. Built with a joint venture/import quality, the DX80 is a sturdy and dependable choice for any construction site.
| Specifications | Value |
|---|---|
| No. | 1004604 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7900 |
| Bucket capacity (m³) | 0.30 ~ 0.32 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV98 VDB24 |
| Rated power (kw/rpm) | 41.4 / 2100 |
| Cylinder diameter × stroke (mm) | 98 x 110 |
| Number of cylinders (PCS) | 4 |
| Working form | 4-stroke, water-cooled, direct injection; Naturally aspirated, air-cooled |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 56 |
| Rod digging force (kN) | 41 |
| Maximum tractive force (kN) | 63 |
| Travel speed (km/h) | 4.9 / 3.1 |
| Turning torque (Nm) | 24.2 |
| Maximum flow of main pump (l/min) | 75.6 * 2 + 18.7 |
| Traveling Hydraulic Circuit (Mpa) | 28 |
| Working Hydraulic Circuit (Mpa) | 28 |
| Fuel Tank (L) | 145 |
| Total transport length (mm) | 6000 |
| Total transport width (mm) | 2290 |
| Total transport height (mm) | 2685 |
| Full cab height (mm) | 2,690 |
| Counterweight ground clearance (mm) | 825 |
| Back end turning radius (mm) | 1800 |
| Onboard width (mm) | 2,200 |
| Total track length (mm) | 2750 |
| Track gauge (mm) | 1,770 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2,220 |
| Maximum digging radius (mm) | 6350 |
| Maximum digging depth (mm) | 4165 |
| Maximum excavation height (mm) | 7120 |
| Maximum unloading height (mm) | 5115 |
| Maximum vertical digging depth (mm) | 3328 |
| Dodging plate width × height (mm) | 2200 x 418 |
