Product Description
Available now in Zhejiang Hangzhou, this 2018 Doosan DX80 excavator eliminates factory wait times and delivers immediate productivity to your jobsite. Powered by a reliable Yanmar 4TNV98 engine producing 41.4 kW at 2100 rpm, this 8-ton machine combines proven performance with rapid deployment capability. Skip the lengthy procurement process—this unit is ready for fast mobilization across the region.
Engineered for versatile construction and earthmoving applications, the DX80 offers a maximum digging depth of 4,165 mm and a digging reach of 6,350 mm. With a 0.30-0.32 m³ bucket capacity, 56 kN bucket digging force, and dual main pumps delivering 75.6 l/min each, this machine handles demanding excavation tasks efficiently. Compact transport dimensions (6,000 mm length × 2,290 mm width) facilitate quick site-to-site transfers throughout Hangzhou and surrounding areas.
- Working weight: 7,900 kg with 145L fuel capacity
- Travel speed: 4.9 km/h for rapid repositioning
- 30° climbing ability and 1,800 mm rear turning radius
- Immediate availability—no production delays
| Specifications | Value |
|---|---|
| No. | 1004756 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7900 |
| Bucket capacity (m³) | 0.30 ~ 0.32 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV98 VDB24 |
| Rated power (kw/rpm) | 41.4 / 2100 |
| Cylinder diameter × stroke (mm) | 98 x 110 |
| Number of cylinders (PCS) | 4 |
| Working form | 4-stroke, water-cooled, direct injection; Naturally aspirated, air-cooled |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 56 |
| Rod digging force (kN) | 41 |
| Maximum tractive force (kN) | 63 |
| Travel speed (km/h) | 4.9 / 3.1 |
| Turning torque (Nm) | 24.2 |
| Maximum flow of main pump (l/min) | 75.6 * 2 + 18.7 |
| Traveling Hydraulic Circuit (Mpa) | 28 |
| Working Hydraulic Circuit (Mpa) | 28 |
| Fuel Tank (L) | 145 |
| Total transport length (mm) | 6000 |
| Total transport width (mm) | 2290 |
| Total transport height (mm) | 2685 |
| Full cab height (mm) | 2,690 |
| Counterweight ground clearance (mm) | 825 |
| Back end turning radius (mm) | 1800 |
| Onboard width (mm) | 2,200 |
| Total track length (mm) | 2750 |
| Track gauge (mm) | 1,770 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2,220 |
| Maximum digging radius (mm) | 6350 |
| Maximum digging depth (mm) | 4165 |
| Maximum excavation height (mm) | 7120 |
| Maximum unloading height (mm) | 5115 |
| Maximum vertical digging depth (mm) | 3328 |
| Dodging plate width × height (mm) | 2200 x 418 |
