Built for precision work in confined spaces, this 2018 Doosan DX80 delivers 8-ton performance with the maneuverability urban jobsites demand. Powered by a reliable Yanmar 4TNV98 engine producing 41.4kW at 2100rpm, this excavator tackles digging, grading, and demolition tasks with consistent hydraulic power. A maximum digging depth of 4,165mm and 6,350mm reach handle trenching and foundation work efficiently, while the 0.30-0.32m³ bucket capacity moves material at a productive pace.
Hydraulic muscle comes from 56kN bucket digging force and dual 75.6 L/min pumps that respond instantly to operator input. Compact dimensions—6,000mm transport length and 1,800mm tail swing radius—allow positioning in tight residential or commercial sites without sacrificing stability. The machine's 7,900kg working weight provides solid grounding without excessive ground pressure.
Currently located in Fujian, this DX80 arrives site-ready with proven Doosan engineering. Fuel capacity of 145L supports extended shifts, while the 4.9km/h travel speed repositions quickly between dig zones. Contact Fair Trade Machinery for specifications, shipping logistics, and competitive export pricing on this versatile 8-ton workhorse.
| Specifications | Value |
|---|---|
| No. | 1015969 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7900 |
| Bucket capacity (m³) | 0.30 ~ 0.32 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV98 VDB24 |
| Rated power (kw/rpm) | 41.4 / 2100 |
| Cylinder diameter × stroke (mm) | 98 x 110 |
| Number of cylinders (PCS) | 4 |
| Working form | 4-stroke, water-cooled, direct injection; Naturally aspirated, air-cooled |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 56 |
| Rod digging force (kN) | 41 |
| Maximum tractive force (kN) | 63 |
| Travel speed (km/h) | 4.9 / 3.1 |
| Turning torque (Nm) | 24.2 |
| Maximum flow of main pump (l/min) | 75.6 * 2 + 18.7 |
| Traveling Hydraulic Circuit (Mpa) | 28 |
| Working Hydraulic Circuit (Mpa) | 28 |
| Fuel Tank (L) | 145 |
| Total transport length (mm) | 6000 |
| Total transport width (mm) | 2290 |
| Total transport height (mm) | 2685 |
| Full cab height (mm) | 2,690 |
| Counterweight ground clearance (mm) | 825 |
| Back end turning radius (mm) | 1800 |
| Onboard width (mm) | 2,200 |
| Total track length (mm) | 2750 |
| Track gauge (mm) | 1,770 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2,220 |
| Maximum digging radius (mm) | 6350 |
| Maximum digging depth (mm) | 4165 |
| Maximum excavation height (mm) | 7120 |
| Maximum unloading height (mm) | 5115 |
| Maximum vertical digging depth (mm) | 3328 |
| Dodging plate width × height (mm) | 2200 x 418 |
