Product Description
With a working weight of 7900 kg and an 8-ton capacity, the Doosan DX80 offers robust performance for demanding tasks. Powered by a Yanmar 4TNV98 VDB24 engine, delivering 41.4 kW at 2100 rpm, this excavator ensures reliable and efficient operation. Equipped with a backhoe bucket with a capacity ranging from 0.30 to 0.32 m³, it excels in various excavation projects.
- Enhanced visibility from the full cab height of 2,690 mm, providing operators with a clear view of the work area.
- Stability and control are maintained with a ground specific pressure of 37 Kpa and a maximum tractive force of 63 kN.
- The 4-stroke, water-cooled, direct injection engine ensures smooth and consistent power delivery, supporting a travel speed of up to 4.9 km/h.
- Operator comfort is prioritized with features like a spacious cabin and ergonomic controls, reducing fatigue during long hours of operation.
Located in 浙江, this 2022 model is ready to meet your construction needs with its versatile capabilities and operator-focused design.
| Specifications | Value |
|---|---|
| No. | 1000152 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7900 |
| Bucket capacity (m³) | 0.30 ~ 0.32 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV98 VDB24 |
| Rated power (kw/rpm) | 41.4 / 2100 |
| Cylinder diameter × stroke (mm) | 98 x 110 |
| Number of cylinders (PCS) | 4 |
| Working form | 4-stroke, water-cooled, direct injection; Naturally aspirated, air-cooled |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 56 |
| Rod digging force (kN) | 41 |
| Maximum tractive force (kN) | 63 |
| Travel speed (km/h) | 4.9 / 3.1 |
| Turning torque (Nm) | 24.2 |
| Maximum flow of main pump (l/min) | 75.6 * 2 + 18.7 |
| Traveling Hydraulic Circuit (Mpa) | 28 |
| Working Hydraulic Circuit (Mpa) | 28 |
| Fuel Tank (L) | 145 |
| Total transport length (mm) | 6000 |
| Total transport width (mm) | 2290 |
| Total transport height (mm) | 2685 |
| Full cab height (mm) | 2,690 |
| Counterweight ground clearance (mm) | 825 |
| Back end turning radius (mm) | 1800 |
| Onboard width (mm) | 2,200 |
| Total track length (mm) | 2750 |
| Track gauge (mm) | 1,770 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2,220 |
| Maximum digging radius (mm) | 6350 |
| Maximum digging depth (mm) | 4165 |
| Maximum excavation height (mm) | 7120 |
| Maximum unloading height (mm) | 5115 |
| Maximum vertical digging depth (mm) | 3328 |
| Dodging plate width × height (mm) | 2200 x 418 |
